SamplexPower EVO-RC User Manual

SAMLEX AMERICA INC. | 19
APPENDIX A
4.1 PARAMETER SETUP MENU MAPS
4.1.1 General Information
Up to 63 operating parameters (Figs 4.1 and 4.2) can be programmed to suit the desired operating conditions.
The 63 programming parameters have been arranged under 7 "PARAMETER GROUPS" (Displayed under heading"SELECT
GROUP") as shown in Parameter Setup Menu Map for "PARAMETER GROUPS" 1 - 4 in Fig 4.1 & for "PARAMETER
GROUPS" 5 - 7 in Fig 4.2.
i
INFO
Parameter Setup Menu Maps in Figs 4.1 & 4.2 have been explained using LCD screen displays with information
as seen on the actual LCD screens.
• All values shown in the second row of setup screen displays are the default parameters for EVO-
2212/3012.
• All voltage values related to battery voltages are the default values for 12V versions i.e. EVO-2212/3012
SECTION 4 | Parameter Setup
