70 | SAMLEX AMERICA INC.
APPENDIX A
5.1 SD CARD GENERAL INFORMATION
SD Card slot has been provided for using an SD card for (i) data logging and (ii) saving programmed parameters. SD card
supports FAT16/FAT32 format up to 16GB in size.
When the SD card is inserted, the LCD screen will display the following.
S D C A R D D E T E C T E D
V 2 . x x x G B
SD card is detected and shows the Version and capacity. "xx"
is the capacity.
S D C A R D
U N U S A B L E !
Not supported card.
CAUTION!
Do not remove SD Card when data logging has been enabled (may corrupt les). Follow "STOP SD
CARD" procedure (Section 4.10) before removing the SD Card.
ATTENTION!
Ne pas retirer la carte SD lorsque « data logging » a été activée (peut corrompue les chiers).
Suivez la procédure "STOP SD CARD" (article 4.10 ) avant de retirer la carte SD .
5.2 DATA LOGGING
5.2.1 General Information
NOTES:
1. Data logging records status of various operating parameters and events with respect to its internal Real
Time Clock (RTC). It is, therefore, recommended that before starting data logging, the current date and
time should be set (if not set already) using programming Parameter “TIME SETTING” (Section 4.9)
2. In the factory default condition, data logging has been enabled at 1 sec recording interval [Parameter
“DATALOG TIME” (Section 4.8.2.10) has been set to option “1 = 1 sec”]. Hence, data logging will
commence as soon as SD Card is inserted
3. To disable data logging, parameter “DATALOG TIME” (Section 4.8.2.10) has to be set at option “0 =
Disable”
As explained at Section 5.1 above, an SD Card (FAT16 / FAT32, up to 16 GB) may be used for Data Logging wherein up
to 28 operating parameters including “Event” will be recorded on the SD Card automatically as soon as the SD Card is
inserted in the SD Card Slot of EVO-RC. [Provided parameter “DATALOG TIME” (Section 4.8.2.10) has NOT been set to
“0 = Disable”)]. The 28 Data Fields are shown in Fig 5.1.
SECTION 5 | SD Card
