SamplexPower EVO-RC User Manual

16 | SAMLEX AMERICA INC.
APPENDIX A
SECTION 3 | Operation
Fig 3.4 (a) Menu Map of Operating Mode Screens
in Charger Only Mode (AC input is available)
Fig 3.4 (b) Menu Map of Operating Mode Screens
in Charger Only Mode (No AC input)
DISPLAY
SCREEN NO.
DISPLAY SCREENS IN
CHARGER ONLY MODE
(NO AC INPUT)
1
S T A N D B Y
B A T T E R Y 1 2 . 0 0 0 V
ò ñ
2
S T A N D B Y
O U T P U T 0 . 0 0 V
ò ñ
3
S T A N D B Y
G R I D 0 . 0 0 V
ò ñ
4
S T A N D B Y
G E N 0 . 0 0 V
ò ñ
5
S T A N D B Y
Y Y Y Y / MM / D D H H : MM
ò ñ
6
S T A N D B Y
I D = 1 R C = X X X
1
ò ñ
7
S T A N D B Y
E V O - X X X X
1
V X . X X
1
DISPLAY
SCREEN NO.
DISPLAY SCREEN
1
C H A R G I N G 0 - C C
2
1 2 0 . 0 0 V
ò ñ
2
C H A R G I N G 0 - C C
2
G R I D 6 0 . 0 0 H z
ò ñ
3
C H A R G I N G 0 - C C
2
G E N 0 . 0 0 V
ò ñ
4
C H A R G I N G 0 - C C
2
G E N 0 . 0 0 H z
ò ñ
5
C H A R G I N G 0 - C C
2
I N P U T 2 0 . 0 0 A
ò ñ
6
C H A R G I N G 0 - C C
2
I N P U T 2 4 0 0 W
ò ñ
7
C H A R G I N G 0 - C C
2
I N P U T 2 4 0 0 V A
ò ñ
8
C H A R G I N G 0 - C C
2
I N P U T P F = 1 . 0 0 0
ò ñ
9
C H A R G I N G 0 - C C
2
O U T P U T 1 2 0 . 0 0 V
ò ñ
10
C H A R G I N G 0 - C C
2
O U T P U T 1 5 . 0 0 A
ò ñ
11
C H A R G I N G 0 - C C
2
O U T P U T 1 2 0 0 W
ò ñ
12
C H A R G I N G 0 - C C
2
O U T P U T 1 2 0 0 V A
ò ñ
13
C H A R G I N G 0 - C C
2
O U T P U T P F = 1 . 0 0 0
ò ñ
14
C H A R G I N G 0 - C C
2
B A T T E R Y 1 2 . 0 0 0 V
ò ñ
15
C H A R G I N G 0 - C C
2
B A T T E R Y 4 0 . 0 A
ò ñ
16
C H A R G I N G 0 - C C
2
B A T T E X T 0 . 0 A
ò ñ
17
C H A R G I N G 0 - C C
2
B A T T E R Y 2 5 . 0 C
ò ñ
18
C H A R G I N G 0 - C C
2
I D = 1 R C = X X X
1
ò ñ
19
C H A R G I N G 0 - C C
2
E V O - X X X X
1
V X . X X
1
UP
KEY
UP
KEY
UP
KEY
UP
KEY
UP
KEY
UP
KEY
DOWN
KEY
DOWN
KEY
DOWN
KEY
DOWN
KEY
DOWN
KEY
DOWN
KEY
UP
KEY
UP
KEY
UP
KEY
UP
KEY
UP
KEY
UP
KEY
UP
KEY
UP
KEY
UP
KEY
UP
KEY
UP
KEY
UP
KEY
UP
KEY
UP
KEY
UP
KEY
DOWN
KEY
DOWN
KEY
DOWN
KEY
DOWN
KEY
DOWN
KEY
DOWN
KEY
DOWN
KEY
DOWN
KEY
DOWN
KEY
DOWN
KEY
DOWN
KEY
DOWN
KEY
DOWN
KEY
DOWN
KEY
DOWN
KEY
UP
KEY
UP
KEY
UP
KEY
DOWN
KEY
DOWN
KEY
DOWN
KEY
LEGEND FOR FIGS 3.4(a) and 3.4(b):
1. • The 3-digit No. XXX in “RC-XXX” indicates the Firmware Revision No. for the Remote
Control EVO-RC
• The 4-digit No. XX.X in EVO-VX.XX denotes the Firmware Revision No. for the EVO™
Inverter/Charger
• The 4-digit No. XXXX in EVO-XXXX denotes the Model No. of Evolution™ Series
Inverter/Charger
i.e. EVO-2212 / 2224 / 3012 / 4024
2. The display on the top right corner of the 19 Display Screens (Display Screen Nos. 1 to
19) in Fig 3.4(a) indicates the Charging Prole & the Charging Stage. Refer to Section
3.6.2 & Table 3.2 for details.
3. The following convention has been used to show up and down scrolling of the screens:
UP
ò
KEY
Press Up Key to scroll to the next screen in the downward direction
towards higher Screen Nos
ñ
DOWN
KEY
Press Down Key to scroll to the previous screen in the upward direction
towards lower Screen Nos
4. Parameter values shown in the screens are the default values for the 12V versions
i.e. EVO-2212/3012.
