16
Specifications
Master Section (Rear Panel)
Input 2 TRS Balanced 1/4" (Left-Right) or (Left mono)
Impedance 15 k Ohms balanced
Max. input level +26 dBu balanced
CMRR: Min 40dB, >55 dB @ 1 kHz
Master Section (Front Panel)
Master Volume control 0 - 10
Master Level Meters 6 Segment LED (–24 to OL)
Master Inject 1/4" TRS jack (Left-Right)
Controls ST/2CH Switch, Volume Control,Balance Control
Link Output
Connectors 2-1/4" TRS Balanced (Left-Right) Parallel to Main Input
Max Output Level Matches Main Input
Channels
Impedance 10 k Ohms unbalanced
Max. input level +21 dBu unbalanced
Level Meters 6 Segment LED (–24 to OL) (load compensating)
Outputs 2 - 1/4" TRS (Left-Right) Headphone outputs per Channel
Max. output level 140 mW at 32 ohms, 385mW at 66 ohms.
Impedance minimum 8 Ohms
Controls EQ Shape Switch, Volume Control
Global Specifications
Frequency response 10 Hz to 32 kHz, +0/- 3 dB
Noise > 90 dB, unweighted, 22 Hz to 22 kHz
THD 0.008 % typ. @ +4 dBu, 1 kHz
Power Supply
Mains Voltages USA/Canada 105-125 VAC ~, 60 Hz
Mains Voltages Europe 215 – 254 VAC~,50Hz
Power Inlet Standard IEC receptacle / with fuse
Power Consumption 29 Watts Max.
Physical
Dimensions 1 3/4" (44.5 mm) * 19" (482.6 mm) * 8 1/2" (217 mm)
Net Weight 5.5lbs., (2.5 kg)
Shipping Weight 8lbs., (3.6 kg)
