Samson MDA1 User Manual

EN FR DE ES IT
Type Mono Active Direct Box
Frequency Response 18Hz to 35kHz -3dB
Maximum Input +2dBu (9 Volt Battery)
Gain +4.8dB
Dynamic Range 105dB @ Balanced Output
Noise Floor -98dB (Pad Off)
Total harmonic distortion <0.05% from 18Hz to 35kHz
Input impedance 1MΩ (Pad On or Off)
Output Impedance 200Ω
Input PAD Switch 0dB, -15dB
Ground Lift Disconnects XLR pin-1 (Output)
Connectors 1/4” Phone Jack, unbalanced (In & Thru)
XLR balanced (Output)
Power Supply 48V Phantom Power or 9 Volt battery
Construction 14 gauge steel chassis
Dimensions 5” x 3.38” x 1.95”
127mm x 86mm x 50mm
Weight 1.34lb
611g
Specifications
