Owner’s Manual
11
Quickstart Continued
5. If the receiver and transmitter have not been previously paired press and hold
the pair button on the RXD1m receiver for >3 seconds until the LED begins to
flash (amber). Press and continue to hold the power button on the transmitter
until the LED indicators on both units light steadily indicating that the receiver
and transmitter are paired and ready for operation.(figure 4)
6. Turn on the connected amplifier or mixer but leave the PA system’s volume at
the minimum level. Turn the volume control of your RXD1m fully clockwise, this
is unity gain. Speak or sing into the microphone at a normal performance level
while turning up the PA system’s volume control until you reach the desired
output level.
7. NOTE: Only two XPDm systems can be used within close proximity to each other.
