RESOLV 120a Connections
Unbalanced 1/4” to RCA Cable
Un-Balanced XLR to RCA Cable
RESOLV 120a Wiring Guide
There are several ways to interface the RESOLV 120a depending on your exact monitoring set-up. The RESOLV 120a fea-
tures both Preamp Level and Speaker Level inputs and outputs, so connecting to any active or passive satellite speakers
is easy. Follow the cable diagrams below for connecting your monitor system.
Speaker Cable (Un-Shielded)
Note: Just about all un-shielded speaker wire will have a marking indicating the negative side. To avoid phase cancelation
problems, be sure to maintain the correct connection for the positive and negative sides throughout your system.
