RESOLV 120a Layout
1
2
3
5
6
4
1 GRILL SCREEN - Tough cloth and PVC frame
construction provides durable and stylish pro-
tection for the speaker.
2 ENCLOSURE - Rigid MDF Construction.
3 FINISH - Sleek black oak vinyl finish.
4 TRANSDUCER - Heavy Duty 10,” long excursion
(25mm) extended range low frequency transducer.
5 BUTYL SURROUND - Provides maximum excur-
sion while maintaining tight bass response.
6 NON-SKID FEET - Large rubber feet keep enclo-
sure in place even at high sound pressure levels.
7 TUNED PORT - Quiet port design offering linear
extended low frequency response. (Rear of unit.)
Front View Layout
