Samson RESOLV 80a User Manual

45
ESPAÑOL
Conexiones del RESOLV 80a
Tip (signal)
Sleeve (ground)
Tip (signal)
Sleeve (ground)
Tip (signal)
Sleeve (ground)
Tip (signal)
Signal (tip)
Signal (ring)
Signal (tip)
Signal (ring)
Ring (signal)
Sleeve (ground)
Ground
Ground
Tip (signal)
Signal (tip)
Signal (ring)
Signal (tip)
Signal (ring)
Ring (signal)
Sleeve (ground)
Ground
Ground
Tip (signal)
Signal
Signal
Sleeve (ground)
Ground
Ground
Tip (signal)Signal
Signal
Sleeve (ground)
Ground
Ground
Cable de 6,3 mm no balanceado a RCA
Cable XLR no balanceado a RCA
Guía de cableado del RESOLV 80a
Hay varias formas de interconectar el RESOLV 80a, dependiendo de su montaje de monitorización
concreto. Para la conexión de su sistema de monitorización vea los siguientes diagramas de cables.
Cable XLR a XLR balanceado
Cable 6,3 mm balanceado a 6,3 mm
Cable 6,3 mm no balanceado a 6,3 mm
Cable RCA a RCA
