Samson RESOLV SE5 - Page 16

Specifications
16
SE6 SE8
6.5” woven carbon fiber 8” woven carbon fiber
1.25” Silk Dome 1.25” Silk Dome
2-way Bass Reflex System 2-way Bass Reflex System
Vinyl wrapped 3/4” (18mm) MDF cabi-
net with painted front baffle
Vinyl wrapped 3/4” (18mm) MDF cabi-
net with painted front baffle
40Hz - 27kHz +/-3dB 30Hz - 27kHz +/-3dB
3.19kHz 24dB/oct Linkwitz-Riley 3.19kHz 24dB/oct Linkwitz-Riley
25 Watts RMS 25 Watts RMS
75 Watts RMS 75 Watts RMS
RCA RCA
XLR, ¼” TRS Phone XLR, ¼” TRS Phone
10k ohm 10k ohm
VOLUME Control
HF LEVEL (-2dB, 0dB, +2dB, +4dB)
VOLUME Control
HF LEVEL (-2dB, 0dB, +2dB, +4dB)
175W 175W
100V - 120V T2.0AL (slow blow)
220V - 240V T1.0AL (slow blow)
100V - 120V T2.0AL (slow blow)
220V - 240V T1.0AL (slow blow)
9.3” x 9.9” x 13.6”
236mm x 251mm x 346mm
11.2” x 12” x 16.25”
285mm x 304mm x 413mm
18lbs
8.2kg
25lbs
11.4kg
