15
Specifications
Inputs
Female Balanced XLR
Impedance Balanced >15k Ohms
Max. Input level +26dBu balanced
Outputs
Male Balanced XLR
Impedance Balanced 100 Ohms
Max. Output Level +26 dBu
Global Specifications
Frequency Response <10 Hz to >90 kHz, +0/-3 dB
Signal to Noise
(Ref +4 dBu), 22 Hz to 22 kHz, un-weighted 90dB high out, mid 90dB, low 94dB, all outs >100dB muted
CMRR Min.40dB, >55 dB @ 1 kHz
Crossover
Crossover Type Linkwitz-Riley, 24 dB/Octave
Crossover 1 Channel 1 35 to 800Hz
350 to 8kHz / with 10X multiplier
Crossover 1 Channel 2 35 to 800Hz
350 to 8kHz / with 10X multiplier
Function Switches
Front Panel
High Pass Filter -3dB @ 25Hz 2 pole, 12dB/Octave
Mute For individual outputs
Phase Inverts the phase of the individual output
Power Supply
Mains Voltages USA/Canada 105-125 VAC ~, 60 Hz
Mains Voltages Europe 215 – 254 VAC~,50Hz
Power Consumption 14 Watts
Power Inlet Standard IEC receptacle / with Fuse
Physical
Dimensions 1 3/4" (44,5 mm) * 19" (482,6 mm) * 8 1/2" (217 mm)
Net Weight 6.6lbs., (3 kg)
Shipping Weight 9.4lbs., (4,3 kg)
