6. Turn the VOLUME controls on the SR266 fully clockwise. While singing or
speaking into the HT6 transmitters slowly raise the input volume controls on your
mixer, amplifier, or karaoke system until the desired level is reached.
OVERALL SYSTEM SPECIFICATIONS
Operating Frequency VHF 173.80 MHz to 215.2 MHz
Number of Channels Fixed channel
Frequency Stability ±0.005%
Modulation Mode FM
Maximum Deviation ±15 kHz
Operating Range 250' (line of sight)
Operating Temperature Range 40° F (4° C) to 110° F (43° C)
Frequency Response 80 Hz to 15 kHz
SR266 RECEIVER SPECIFICATIONS
Image Rejection 30 dB
Dynamic range 95.5 dB
Maximum Output 900mV
Sensitivit
y 10 dBµV for 48 dB S/N
Output Connectors Two - 1/4" TS ("mono") phone jack
Audio Output Levels -10dB unbalanced (1/4" phone connector),
Power Supply 100-240V AC (50/60 Hz) to 12V DC 1A
Net Weight 0.38kg
HT6 Handheld TRANSMITTER SPECIFICATIONS
RF Power Output 10 mW
Microphone Element H6 Dynamic unidirectional
TX Battery Life (9-volt alkaline battery) 9-hours
Current Consumption 30 mA typical
Net Weight 0.18kg
