Samson TROVIS 5573 - Page 106

16-24 EB 5573 EN
Appendix A (conguration instructions)
System Anl 11.2
WW
KW
BE
BA
AE
RK
AF1
SF2
RüF1
VF1 VF2VF2
RüF2UP1
SF1RK2 RF1
SLPRK1 ZP
Default setting
CO1->F01 - 0 (without RF1)
CO1->F02 - 1 (with AF1)
CO1->F03 - 1 (with RüF1)
CO4->F01 - 1 (with SF1)
CO4->F02 - 1 (with SF2)
CO4->F03 - 0 (without RüF2)
CO4->F10 -0(DHWcirculationreturnowinstoragetank)
CO5'->F10
Functionofthe0to10Voutput:
− 1=ControlsignalRK1
− 2=ControlsignalRK2
− 6=Externaldemand
When
CO1->F18-1
− 7=SLPspeed
When
CO4->F21-1
− 5=Outdoortemperature When
CO5->F23-1
Direction 'AA'
