16-68 EB 5573 EN
Appendix A (conguration instructions)
When outdoor-temperature-compensated control with gradient characteristic is used, the re-
turn ow temperature is limited to a xed value by equating the 'Base point for return ow
temperature' and 'Max. return ow temperature' (PA1, 2 ) parameters.
Functions Default Conguration
ReturnowsensorRüF1/RüF2 1
1.0
CO1,2,4->F03-1
KP (limiting factor): 0.1 to 10.0
ReturnowtemperaturelimitationwithP
algorithm
1)
0 CO5->F16
1)
IfthecontrollerindicatesCO5->F00-1,anyaccesstothereturnow,owrateandcapacity
settings is locked.
Parameters Default Parameter level: value range
Returnowgradient 1.2 PA1, 2 : 0.2 to 3.2
Returnowlevel 0.0°C PA1,2:–30.0to+30.0°C
Basepointforreturnowtemperature: 65.0°C PA1,2:5.0to90.0°C
Max.returnowtemperature 65.0°C PA1,2,4:5.0to90.0°C
or:
Parameters Default Parameter level: value range
Returnowtemperature,points1to4 65.0°C PA1,2:5.0to90.0°C
To ensure the preset return ow temperature limit can be kept, make sure that the follow-
ing conditions are met:
Î Do not adjust the heating characteristic to ascend too steeply.
Î The speed of the circulation pumps is not set too high.
Î The heating systems have been balanced.
Note
NOTICE
!
