Samson TROVIS 5573 - Page 168

16-86 EB 5573 EN
Appendix A (conguration instructions)
F Function WE Anl
Comments
Function block parameters: value range (default setting)
06 Parallel pump
operation
0
2.1–2.3,
4.1, 4.5
CO4->F06-1
Function block parameters:
Stop parallel pump operation in the event of a system devia-
tion:0to10min(10min)
Flow temperature limit for parallel operation: 20.0 to
90.0°C(40.0°C)
CO4:F06-0:UP1switchedoffduringDHWheating
07 Intermediate
heating
1
2.x, 4.1,
4.5
CO4->F07-1:after20minutesofDHWheating,heating
operation in UP1 circuit reactivated for 10 minutes
CO4->F07-0:storagetankchargingisgivenunlimitedpri-
ority concerning UP1 circuit
08 Priority through
reverse control
0
1.1–1.3,
4.1, 4.5,
11.x
CO4->F08-1:onlywhenCO4->F09-0
Function block parameters:
Start:0to10min(2min)
KP(inuencefactor):0.1to10.0(1.0)
SystemAnl4.5only:controlcircuitHC1,HC2,HC1+HC2
(HC2)
09 Priority through
set-back opera-
tion
0
1.1–1.3,
4.1, 4.5,
11.x
CO4->F09-1:onlywhenCO4->F08-0
Function block parameters:
Start:0to10min(2min)
SystemAnl4.5only:HC1,HC2,HC1+HC2(HC2)
10 Circulation
pump (DHW)
integrated into
the heat ex-
changer
0
1.6, 11.2
CO4->F10-1:ControlofDHWcircuitactivewhilecircula-
tionpump(ZP)isrunning
1
11.6
11 Circulation
pump opera-
tion during
storage tank
charging
0
1.1–1.3,
1.5, 1.6,
2.x, 4.1,
4.5, 11.1,
11.2
CO4->F11-1:Circulationpump(ZP)runsaccordingtotime
schedule during storage tank charging
CO4->F11-0:Circulationpump(ZP)switchedoffduring
storage tank charging
