Design and principle of operation
3 Design and principle of oper-
ation
The TROVIS5573HeatingandDistrictHeat-
ing Controller is used to control up to two
control circuits:
− Control of a primary heat exchanger or
boiler with one mixing heating circuit
and one non-mixing heating circuit (both
outdoor-temperature-compensated) and
control of DHW heating in the secondary
circuit
− Outdoor-temperature-compensated
buffer storage tank control with solid fuel
boiler and solar circuit control
− Control of one outdoor-temperature-
compensated heating circuit and a DHW
heating with two valves in the primary
circuit
− Control of two outdoor-temperature-
compensated heating circuits with two
valves in the primary circuit
TheTROVIS5573HeatingandDistrictHeat-
ingControllerisadaptedtothespecicsys-
tem by setting the appropriate system code
number.Additionalsensorsand/orfunctions
which are not part of the system's basic con-
gurationcanbeselectedoverfunction
blocks. The switch positions and entry of the
key number allow access to the correspond-
inglevels.Fortrainedstaff,theconguration
levels used to set function blocks are indicat-
ed by “CO” and the parameter levels are in-
dicated by “PA”. Data is retrieved and en-
tered at the controller using a rotary push-
button. This process is facilitated by icons
displayed on the LCD.
The rotary switch is used to set the operating
mode and the parameters required for each
circuit.
3.1 Conguration using
TROVIS-VIEW
Thecontrollercanbeconguredwiththe
TROVIS-VIEW software.
In this case, the TROVIS5573Heatingand
District Heating Controller is connected to the
computer at the RJ-45 jack on the side of the
controller.
The TROVIS-VIEW software enables the user
toeasilycongurethecontrolleraswellas
view process parameters online.
TROVIS-VIEW provides a uniform user
interface that allows users to congure and
parameterize various SAMSON devices
using device-specic database modules. The
device module 5573 can be downloaded
free of charge from our website at
uwww.samsongroup.com > DOWNLOADS
> Software & Drivers > TROVIS-VIEW.
Further information on TROVIS-VIEW (e.g.
system requirements) is available on our
website and in the Data Sheet uT6661.
Note
