EB 5573 EN 3-5
Design and principle of operation
3.5 Values for resistance thermometers
Pt1000 sensors
Temperature°C –35 –30 –25 –20 –15 –10 –5 0 +5 +10 +15 +20
ResistanceΩ 862.5 882.2 901.9 921.6 941.2 960.9 980.4 1000.0 1019.5 1039.0 1058.5 1077.9
Temperature°C +25 +30 +35 +40 +45 +50 +55 +60 +65 +70 +75 +80
ResistanceΩ 1097.3 1116.7 1136.1 1155.4 1174.7 1194.0 1213.2 1232.4 1251.6 1270.8 1289.9 1309.0
Temperature°C +85 +90 +95 +100 +105 +110 +115 +120 +125 +130 +135 +140
ResistanceΩ 1328.1 1347.1 1366.1 1385.1 1404.0 1422.9 1441.8 1460.7 1479.5 1498.3 1517.1 1535.8
Temperature°C +145 +150 +155 +160 +165 +170 +175 +180 +185 +190 +195 +200
ResistanceΩ 1554.6 1573.3 1591.9 1610.5 1629.1 1647.7 1666.3 1684.8 1703.3 1721.7 1740.2 1758.6
PTC sensors
Temperature°C –20 –10 0 +10 +20 +30 +40 +50
ResistanceΩ 693 756 824 896 971 1050 1133 1220
Temperature°C +60 +70 +80 +90 +100 +110 +120
ResistanceΩ 1311 1406 1505 1606 1713 1819 1925
Type5244 (remote control unit)
Switch position
, terminals 1 and 2
Temperature°C 10 15 20 25 30
ResistanceΩ 679 699 720 741 762
Ni1000 sensors
Temperature°C –60 –50 –40 –30 –20 –10 0 +10 +20 +30 +40
ResistanceΩ 695 743 791 841 893 946 1000 1056 1112 1171 1230
Temperature°C +50 +60 +70 +80 +90 +100 +110 +120 +130 +140 +150
ResistanceΩ 1291 1353 1417 1483 1549 1618 1688 1760 1833 1909 1986
Temperature°C +160 +170 +180 +190 +200 +210 +220 +230 +240 +250
ResistanceΩ 2066 2148 2232 2318 2407 2498 2592 2689 2789 2892
