EB 5573 EN 8-11
Setup
Temperature at solar collector sensor VF3
TemperatureatreturnowsensorRüF
Temperature at storage tank sensor SF1
Temperature at storage tank sensor SF2
Temperature at storage tank sensor of solar circuit
2. Conrmadatapoint[Û]toreadtheassociatedsetpoint/limit.Thedateisdisplayed
when the time reading appears.
8.6 Operating the controller in manual mode
Switchtomanualmodetocongureallcontrolleroutputs.
Risk of damage of the heating circuit through low temperatures.
The frost protection does not function when the controller is in manual mode.
How to proceed:
1. Turn the rotary switch to
(manual level).
2. Select output depending on the control circuit [q]:
POS_ Correction value adjusted in percent
UP_ Switching of the circulation pump (heating)
SLP Switching of the storage tank charging pump
TLP Switching of the heat exchanger charging pump
CP Switching of the solar circuit pump
ZP Switching of the circulation pump (DHW)
3. Conrmoutput[Û].
The reading blinks.
4. Changethepositioningvalue/switchingstate[q].
5. Conrmchange[Û].
Themodiedvaluesremainactiveaslongasthecontrollerisinmanualmode.
NOTICE
!
