Appendix A (conguration instructions)
16 Appendix A (conguration instructions)
ThisAppendixcontainsinformationonthecongurationofthecontroller.
16.1 Systems
Boiler plants
Single-stageboilersystemscanbeconguredtoincludeanysystemwhoseheatingcircuits
and DHW circuit include just one heat exchanger. These systems are Anl 1.0, 1.5, 1.6, 2.x,
3.0, 3.5, 4.0, 4.1 and 16.x.
Theboilercanbecontrolledbyanon/offoutput(CO1->F12-0).
RK1 RüF1 VF1 UP1 RF1
BE
BA
AE
RK
RK1_2 Pkt VF1 UP1 RF1
BE
BA
AE
RK
Boiler
Single-stage
Fig.16-1: Conguration of a boiler system
