Samson TROVIS 5573 - Page 86

16-4 EB 5573 EN
Appendix A (conguration instructions)
System Anl 1.1
BE
BA
AE
RK
RF1UP1SLP (RK2) SF1
WW
KW
AF1VF1RüF1RK1 VF4 ZP
Default setting
CO1->F01 - 0 (without RF1)
CO1->F02 - 1 (with AF1)
CO1->F03 - 1 (with RüF1)
CO4->F01 - 1 (with SF1)
CO4->F02 - 0 (without SF2)
CO4->F05
- 0 (without VF4)
CO5'->F10
Functionofthe0to10Voutput:
− 1=ControlsignalRK1
− 6=Externaldemand
When
CO1->F18-1
− 5=Outdoortemperature When
CO5->F23-1
Direction 'AA'
