5 Exploded View & Parts List
5-2
5-2 DE17PSQFV/XAX Parts List
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-00778E ASSY COVER P-FRONT;DI17PS,ABS HB,BLACK 1 S.A
M0215 BN07-00218A LCD-PANEL;LTM170E8-L21,Dali2,6BIT FRC,35 1 S.A
T0010 BN61-01598A HOLDER-SUB PCB;DI17PS,ABS HB,T1.8,IV16,D 1 S.N.A
M0017 BN91-00836T ASSY CHASSIS-E19;DE17PSQAQ/EDC,DALI2 1 S.A
M0215 BN44-00103B INVERTER;RL17,SIC842,13.0~14.5V,2.0MA,7. 1 S.A
T0178 BN63-01034A SHIELD-PCB;DALI 17,SECC,T1.0 1 S.N.A
M0006 BN63-01035C COVER-REAR;DALI 17,ABS HB BK21,CLP-2402H 1 S.A
M0173 BN96-00890B ASSY STAND P-CAP;DALI 17_19,ABS HB,BLACK 1 S.A
M0003 BN96-01998B ASSY STAND P;DE17P (S/M 173 PLUS),ABS HB 1 S.A
