..2 M0081 6003-001336 SCREW-TAPTITE;CH,+,S,M3,L5.5,ZPC(YEL),SW 4 S.N.A
..2 T0081 BN96-00837A ASSY MISC P-SHIELD PCB;DI17PS,SECC T1.0 1 S.N.A
...3 T0178 BN63-01034A SHIELD-PCB;DALI 17,SECC,T1.0 1 S.N.A
..2 M0173 BN96-00890B ASSY STAND P-CAP;DALI 17_19,ABS HB,BLACK 1 S.A
...3 BN63-01038B COVER-REARCAP TOP;DALI,ABS HB BK12,CLP-2 1 S.N.A
...3 CCM1 BN63-01039A SHIELD-CAP;DALI 17,SPTE T0.3 1 S.N.A
0.1 M0017 BN91-00836T ASSY CHASSIS-E19;DE17PSQAQ/EDC,DALI2 1 S.A
..2 M2893 BN39-00419A LEAD CONNECTOR;DS17BS,UL1571#30,UL/CSA,1 1 S.A
..2 M2893 BN39-00431A LEAD CONNECTOR-LVDS;DI17PS,UL1571#30,UL/ 1 S.A
..2 M2893 BN39-00446A LEAD CONNECTOR;DI17PS,UL1061#28,UL/CSA,4 1 S.A
..2 M0215 BN44-00103B INVERTER;RL17,SIC842,13.0~14.5V,2.0MA,7. 1 S.A
..2 T0010 BN61-01598A HOLDER-SUB PCB;DI17PS,ABS HB,T1.8,IV16,D 1 S.N.A
..2 M0014 BN94-00642Q ASSY PCB MAIN-E19;DE17PSQAQ/EDC,DALI2 1 S.A
...3 BZ201 3002-001123 BUZZER-PIEZO;85DB,9VDC,8MA ,4.4KHZ +/- 0 1 S.A
...3 CN101 3711-005506 HEADER-BOARD TO CABLE;BOX,22P,2R,2mm,STR 1 S.A
...3 CN102 3711-005507 HEADER-BOARD TO CABLE;BOX,20P,2R,2mm,STR 1 S.A
...3 T0174 BN97-00512H ASSY SMD;DE17PSQAQ/EDC,DALI2 1 S.N.A
....4 D100 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D101 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D102 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D103 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D104 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D105 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D106 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D107 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D108 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D109 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D110 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D600 0402-000553 DIODE-SCHOTTKY;"SS24,B240",40V,2000mA,DO 1 S.A
....4 ZD100 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD101 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD102 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD103 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD104 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD105 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD106 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD107 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD108 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD109 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD110 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD111 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD112 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD113 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD114 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD115 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD116 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD201 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD202 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 Q201 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q600 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q601 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q602 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q409 0505-001170 FET-SILICON;SI9933ADY-T1,P,-20V,3.4A,0.0 1 S.A
....4 IC109 1003-001538 IC-LCD CONTROLLER;S5D2542X,LQFP,208P,28X 1 S.A
....4 IC109 1003-001789 IC-LCD CONTROLLER;SE59AWJ-LF,PQFP,128P,2 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-001023 IC-EEPROM;24C08,8Kbit,1Kx8Bit,SOP,8P,5x4 1 S.A
6 Electrical Parts List
6-2
Code No.
Loc. No. Description Specification EA SA/SNA
Remarks
To Next Page
