11 Disassembly and Reassembly
11-2
3. Lift up the stand and insert the opening drive into the grooves at each side and press until it clicks.
4. Disconnect function cable and remove 12 screws from the shield.
5. Remove the cover front and remove 4 screws from the panel.
