10
640 x 480 @ 67Hz
640 x 480 @ 72Hz
640 x 480 @ 75Hz
800 x 600 @ 56Hz
800 x 600 @ 60Hz
800 x 600 @ 72Hz
800 x 600 @ 75Hz
832 x 624 @ 75Hz
1024 x 768 @ 87Hz(I) (N/A)
1024 x 768 @ 60Hz
1024 x 768 @ 70Hz
1024 x 768 @ 75Hz
24h Established Timing II
1280 x 1024 @ 75Hz
EF
1152 x 870 @ 75Hz
800 x 600 @ 85Hz (N/A)
1024 x 768 @ 85Hz (N/A)
1280 x 1024 @ 60Hz (N/A)
1280 x 1024 @ 85Hz (N/A)
1600 x 1024 @ 60Hz (N/A)
1600 x 1200 @ 75Hz (N/A)
25h Manufacturers Reserved Timings
1600 x 1200 @ 85Hz (N/A)
80
1680 x 1050 @ 60Hz 16: 10 B3,00
1280 x 1024 @ 60Hz 5: 4 81,80
1280 x 960 @ 60Hz 4: 3
81,40
1152 x 864 @ 75Hz 4: 3
71,4F
No Application 01,01
No Application
01
No Application
01
26~35h Standard Timing Identification
No Application
01
1680x1050 @ 60Hz
36~47h
Detailed Timing / Descriptor
Block 1
146.25 MHz
21,39,90,30,62,1A,27,40,68,
B0,
36,00,DA,28,11,00,00,1C
5A~6Bh
Detailed Timing / Descriptor
Block 2
Monitor Name: SyncMaster
00,00,00,FC,00,53,79,6E,63,
4D,61,73,74,65,72,0A,20,20
Min. Vertical Frequency: 56 Hz 00,00
Max. Vertical Frequency: 75 Hz 00,FD
Min. Horizontal Frequency: 30
KHz
00,38
Max. Horizontal Frequency: 81
KHz
4B,1E
48~59h
Detailed Timing / Descriptor
Block 3
Max. Pixel Clock: 150 MHz
51,0F,00,0A,20,20, 20,20,
20,20,
6C~7Dh
Detailed Timing / Descriptor
Block 4
Monitor Serial Number:
H1AK500000
00,00,00,ff,00,48,31,41,4B,3
5,30,30,30,30,30,0A,20,20
7Eh Extension flag 00
7Fh Checksum XX
DVI
0 1 2 3 4 5 6 7 8 9 A B C D E F
0
00 FF FF FF FF FF FF 00 4C 2D 20 03 XX XX XX
XX
