3-4 EDID table
VGA
0 1 2 3 4 5 6 7 8 9 A B C D E F
0
00 FF FF FF FF FF FF 00 4C 2D 1F 03 XX XX XX
XX
1
XX XX 01 03 6C 2F 1E 78 2A DC 51 A3 59 48 9E
24
2
11 50 54 BF EF 80 B3 00 81 80 81 40 71 4F 01
01
3
01 01 01 01 01 01 21 39 90 30 62 1A 27 40 68
B0
4
36 00 DA 28 11 00 00 1C 00 00 00 FD 00 38 4B
1E
5
51 0F 00 0A 20 20 20 20 20 20 00 00 00 FC 00
53
6
79 6E 63 4D 61 73 74 65 72 0A 20 20 00 00 00
FF
7
00 48 31 41 4B 35 30 30 30 30 30 0A 20 20 00
XX
Byte(Hex) Field Name and Comments Description EDID
00~07h Head Information 00,FF,FF,FF,FF,FF,FF,00
08~09h ID Manufacturer Name SAM 4C,2D
0A~0Bh Product ID Code 031F 1F,03
0C~0Fh Last 5 Digits of Serial Number 0 XXXXXXXXXX
10h Week of Manufacture 1 XX
11h Year of Manufacture 2007 XX
12h EDID Version Number 1 01
13h EDID Revision Number 3 03
Analog Signal Level
0.700, 0.000 (0.700Vp-p)
No Blank -to-black Setup
Separate Syncs. Supported
Composite Sync. Supported
No Sync. on Green Supported
14h Video Input Definition
No Serration Required
6C
15h Max Horizontal Image Size 47
16h Max Vertical Image Size 30
2F
17h Display Gamma 2.2 78
No Standby
No Suspend
Active Off/Very Low Power
RGB Color Display
No sRGB Color Space
Preferred Timing Mode
18h
Power Management and
Supported Feature(s)
No Default GTF Supported
2A
R (x, y) 0.640, 0.349
G (x, y) 0.284, 0.617
B (x, y) 0.142, 0.067
19~22h Chroma Info
W (x, y) 0.313, 0.329
DC,51,A3,59,48,9E,24,11,50
,54
720 x 400 @ 70Hz
720 x 400 @ 88Hz (N/A)
23h Established Timing I
640 x 480 @ 60Hz
BF
