Disassembly and Reassembly
Samsung Electronics 3-7
No Parts Procedure Remark
10 Ass'y Panel-Outlet
1) Panel-Outlet
2) As you push the 2 hooks on each side of
Panel outward, detach the bottom part
of Partition by lifting it toward you.
3) Detach the wire positioned with
Holder Wire.
4) Detach the wire positioned with
Holder Wire.
Rear sideFront side
To Next Page
