General Overview
Samsung Electronics 11
10 Samsung Electronics
Model Name
Indoor Unit
AE200RNWSEG AE200RNWSEG AE200RNWSEG AE260RNWSGG AE260RNWSEG AE260RNWSEG AE260RNWSEG
Outdoor Unit AE040RXEDEG AE060RXEDEG AE090RXEDEG AE090RXEDGG AE040RXEDEG AE060RXEDEG AE090RXEDEG
Hydro
Unit
Power Supply Φ, #, V, Hz 1Ф, 2Line, 220~240V, 50Hz 1Ф, 2Line, 220~240V, 50Hz 1Ф, 2Line, 220~240V, 50Hz
3Ф, 4Line, 380~415V, 50Hz
1Ф, 2Line, 220~240V, 50Hz
1Ф, 2Line, 220~240V, 50Hz 1Ф, 2Line, 220~240V, 50Hz 1Ф, 2Line, 220~240V, 50Hz
Water
Pump
Type (Model Name) -
Centrifurugal
(UPMM 25-9.5)
Centrifurugal
(UPMM 25-9.5)
Centrifurugal
(UPMM 25-9.5)
Centrifurugal
(UPMM 25-9.5)
Centrifurugal
(UPMM 25-9.5)
Centrifurugal
(UPMM 25-9.5)
Centrifurugal
(UPMM 25-9.5)
Motor Input (Max) W 100 100 100 100 100 100 100
Number of Unit EA 1 1 1 1 1 1 1
Flow SENSOR
Type (Model Name) - FLOW SENSOR FLOW SENSOR FLOW SENSOR FLOW SENSOR FLOW SENSOR FLOW SENSOR FLOW SENSOR
Min. flow rates LPM 7.0 7.0 7.0 7.0 7.0 7.0 7. 0
Electric Heater W 2,000 2,000 2,000 6,000 2,000 2,000 2,000
Expansion Vessel Liter 8 8 8 8 8 8 8
Pressure Relief Valve bar 2.9 2.9 2.9 2.9 2.9 2.9 2.9
Air Purge Valve Ф, inch BSPP male 3/8" BSPP male 3/8" BSPP male 3/8" BSPP male 3/8" BSPP male 3/8" BSPP male 3/8" BSPP male 3/8"
Sound *3
Sound
Pressure
Heating Std
dB(A) 26 26 26 26 26 26 26
Cooling Std dB(A)
26 26 26 26 26 26 26
Sound Power Heating Std dB(A)
40 40 40 40 40 40 40
External
Dimension
Net Weight kg 136 136 136 146 146 146 146
Shipping Weight kg 148 148 148 158 158 158 158
Net Dimensions (WxHxD) mm 595x1800x700 595x1800x700 595x1800x700 595x1800x700 595x1800x700 595x1800x700 595x1800x700
Shipping Dimensions (WxHxD) mm 700 x 2,000 x 780 700 x 2,000 x 780 700 x 2,000 x 780 700 x 2,000 x 780 700 x 2,000 x 780 700 x 2,000 x 780 700 x 2,000 x 780
Outdoor
Unit
Power Supply Φ, #, V, Hz 1Ф, 2Line, 220~240V, 50Hz 1Ф, 2Line, 220~240V, 50Hz 1Ф, 2Line, 220~240V, 50Hz 3Ф, 4Line, 380~415V, 50Hz 1Ф, 2Line, 220~240V, 50Hz 1Ф, 2Line, 220~240V, 50Hz 1Ф, 2Line, 220~240V, 50Hz
Compressor
Type - BLDC Twin Rotary BLDC Twin Rotary BLDC Twin Rotary BLDC Twin Rotary BLDC Twin Rotary BLDC Twin Rotary BLDC Twin Rotary
Model - UB4TN8200FE4SS UB4TN8200FE4SS UB8TN8265FJWSG UB8TN8265FJWSG UB4TN8200FE4SS UB4TN8200FE4SS UB8TN8265FJWSG
Oil Type - POE POE POE POE POE POE POE
Condenser Size - 2RX28S 2RX28S 2RX46S 2RX46S 2RX28S 2RX28S 2RX46S
Motor
Type (Model) - SIC- 67FV-F135-2 SIC- 67FV-F135-2 FMDC531SSA FMDC531SSA SIC- 67FV-F135-2 SIC- 67FV-F135-2 FMDC531SSA
Quantity EA 1 1 1 1 1 1 1
CODE No - DB31-00492A DB31-00492A DB31-00579A DB31-00579A DB31-00492A DB31-00492A DB31-00579A
Fan
Air Flow Rate Cooling CMM 40 43 66 66 40 43 66
Number of Unit EA 1 1 1 1 1 1 1
4-Way Valve Type (Model) SHF-7H-34U SHF-7H-34U SHF -11H SH F -11H SHF-7H-34U SHF-7H-34U SHF -11H
Base Heater Power Input W N/A N/A 150 150 N/A N/A 150
Sound*3
Sound
Pressure
Heating Std dB(A)
44 47 49 49 44 47 49
Cooling Std dB(A) 46 47 49 49 46 47 49
Night Mode dB(A) - 35 35 35 - 35 35
Sound Power
Heating Std dB(A)
58 60 64 64 58 60 64
Cooling Std dB(A) 61 62 63 63 61 62 63
External
Dimension
Net Weight kg
46.5 46.5 73.0 72.0 46.5 46.5 73.0
Shipping Weight kg 49.5 49.5 81.5 80.5 49.5 49.5 81.5
Net Dimensions (WxHxD) mm 880 x 638 x 310 880 x 638 x 310 940 x 998 x 330 940 x 998 x 330 880 x 638 x 310 880 x 638 x 310 940 x 998 x 330
Shipping Dimensions
(WxHxD)
mm 1,023 x 742 x 413 1,023 x 742 x 413 995 x 1,178 x 426 995 x 1,178 x 426 1,023 x 742 x 413 1,023 x 742 x 413 995 x 1,178 x 426
Refrigerant
Type -
R32 R32 R32 R32 R32 R32 R32
Control Method - EEV EEV EEV EEV EEV EEV EEV
Factory Charging g 1,200 1,200 1,400 1,400 1,200 1,200 1,400
*1) A2W Condition #1 : (Heating) Water In/Out 30℃/35℃, Outdoor Air 7℃DB/6℃WB; (Cooling) Water In/Out 23℃/18℃, Outdoor Air 35℃[DB].
*2) A2W Condition for ESEER(Cooling) at Water Out 18℃.
*3) Sound pressure was acquired in an anechoic room. Thus actual noise level may be different depending on the installation conditions.
Night mode : Water In/Out 30℃/35℃, Outdoor Air : 7℃[DB]/6℃[WB], Measure point from unit : 3m.
