Model Name
Indoor Unit
AE200RNWMEG AE200RNWMEG AE200RNWMEG AE200RNWMEG AE260RNWMGG AE260RNWMGG AE260RNWMGG
Outdoor Unit AE050RXYDEG AE080RXYDEG AE120RXYDEG AE160RXYDEG AE080RXYDGG AE120RXYDGG AE160RXYDGG
Hydro
Unit
Flow SENSOR
Type (Model Name) - FLOW SENSOR FLOW SENSOR FLOW SENSOR FLOW SENSOR FLOW SENSOR FLOW SENSOR FLOW SENSOR
Min. flow rates LPM 7.0 7.0 12.0 12.0 7.0 12.0 12.0
Electric Heater W 2,000 2,000 2,000 2,000 6,000 6,000 6,000
Expansion Vessel Liter 8 8 8 8 8 8 8
Pressure Relief Valve bar 2.9 2.9 2.9 2.9 2.9 2.9 2.9
Air Purge Valve Ф, inch BSPP male 3/8" BSPP male 3/8" BSPP male 3/8" BSPP male 3/8" BSPP male 3/8" BSPP male 3/8" BSPP male 3/8"
Sound *3
Sound
Pressure
Heating Std dB(A) 26 26 30 30 26 30 30
Cooling Std dB(A) 26 26 30 30 26 30 30
Sound Power Heating Std dB(A) 40 40 44 44 40 44 44
External
Dimension
Net Weight kg 130 130 130 130 140 140 140
Shipping Weight kg 142 142 142 142 152 152 152
Net Dimensions (WxHxD) mm 595x1800x700 595x1800x700 595x1800x700 595x1800x700 595x1800x700 595x1800x700
595x1800x700
Shipping Dimensions
(WxHxD)
mm 700 x 2,000 x 780 700 x 2,000 x 780 700 x 2,000 x 780 700 x 2,000 x 780 700 x 2,000 x 780 700 x 2,000 x 780 700 x 2,000 x 780
Outdoor
Unit
Power Supply Φ, #, V, Hz 1Ф, 2Line, 220~240V, 50Hz 1Ф, 2Line, 220~240V, 50Hz 1Ф, 2Line, 220~240V, 50Hz 1Ф, 2Line, 220~240V, 50Hz 3Ф, 4Line, 380~415V, 50Hz 3Ф, 4Line, 380~415V, 50Hz 3Ф, 4Line, 380~415V, 50Hz
Compressor
Type - BLDC Twin Rotary BLDC Twin Rotary BLDC Twin Rotary BLDC Twin Rotary BLDC Twin Rotary BLDC Twin Rotary BLDC Twin Rotary
Model - UB4TN8200FE4SS UB8TN8265FJWSG UB5TN5450FJXSG UB5TN5450FJXSG UB8TN8265FJWSG UB5TN5450FJXSG UB5TN5450FJXSG
Oil - POE POE POE POE POE POE POE
Fan
Air Flow Rate Cooling CMM 51 66 99 118 66 99 118
Number of Unit EA 1 1 2 2 1 2 2
Base Heater W N/A 150 150 150 150 150 150
Sound*3
Sound
Pressure
Heating dB(A) 45 48 50 52 48 50 52
Cooling dB(A) 45 48 50 54 48 50 54
Sound Power
Heating dB 61 63 64 66 63 64 66
Cooling dB 62 64 65 68 64 65 68
External
Dimension
Net Weight kg 58.5 76.0 110.0 110.0 75.0 111.0 111. 0
Shipping Weight kg 62.5
84.5 119.0 119.0 83.5 120.0 120.0
Net Dimensions (WxHxD) mm 880 x 798 x 310 940 x 998 x 330 940 x 1,420 x 330 940 x 1,420 x 330 940 x 998 x 330 940 x 1,420 x 330 940 x 1,420 x 330
Shipping Dimensions
(WxHxD)
mm 1,023x904x413 995 x 1,178 x 426 995 x 1,598 x 426 995 x 1,598 x 426 995 x 1,178 x 426 995 x 1,598 x 426 995 x 1,598 x 426
Operating
Temp. Range
Heating
℃
-25~35 -25~35 -25~35 -25~35 -25~35 -25~35 -25~35
Cooling
℃
10~46 10~46 10~46 10~46 10~46 10~46 10~46
DHW Tank
℃
-25~43 -25~43 -25~43 -25~43 -25~43 -25~43 -25~43
*1) A2W Condition #1 : (Heating) Water In/Out 30℃/35℃, Outdoor Air 7℃DB/6℃WB; (Cooling) Water In/Out 23℃/18℃, Outdoor Air 35℃DB.
*2) A2W Condition for ESEER(Cooling) at Water Out 18℃.
*3) Sound pressure was acquired in an anechoic room. Thus actual noise level may be different depending on the installation conditions.
Product Specifications (cont.)

Samsung AE260RNWSEG Specifications

General

Brand	Samsung
Model	AE260RNWSEG
Category	Heat Pump
Language	English
