Samsung AM160FNBFGB/EU Installation Manual

64
Appendix
Model specification (weight and dimension)
Type Model Net weight Net dimension (W x D x H)
DVM Hydro unit
AM160FNBDEH/EU 29.0 kg 518 x 330 x 627 mm
AM320FNBDEH/EU 33.0 kg 518 x 330 x 627 mm
AM500FNBDEH/EU 40.0 kg 518 x 330 x 627 mm
Hydro unit HT
AM160FNBFEB/EU 104 kg 518 x 330 x 1,210 mm
AM160FNBFGB/EU 105 kg 518 x 330 x 1,210 mm
AM250FNBFEB/EU 104 kg 518 x 330 x 1,210 mm
AM250FNBFGB/EU 105 kg 518 x 330 x 1,210 mm
Outdoor unit (DVM S HP)
AM080FXVAGH 190 kg 880 x 765 x 1,695
AM100FXVAGH 190 kg 880 x 765 x 1,695
AM120FXVAGH 190 kg 880 x 765 x 1,695
AM140FXVAGH 235 kg 1,295 x 765 x 1,695
AM160FXVAGH 278 kg 1,295 x 765 x 1,695
AM180FXVAGH 300 kg 1,295 x 765 x 1,695
AM200FXVAGH 300 kg 1,295 x 765 x 1,695
AM220FXVAGH 300 kg 1,295 x 765 x 1,695
Outdoor unit (DVM S HR)
AM080FXVAGR 195 kg 880 x 765 x 1,695
AM100FXVAGR 195 kg 880 x 765 x 1,695
AM120FXVAGR 195 kg 880 x 765 x 1,695
AM140FXVAGR 241 kg 1,295 x 765 x 1,695
AM160FXVAGR 284 kg 1,295 x 765 x 1,695
AM180FXVAGR 306 kg 1,295 x 765 x 1,695
AM200FXVAGR 306 kg 1,295 x 765 x 1,695
AM220FXVAGR 306 kg 1,295 x 765 x 1,695
Outdoor unit (DVM ECO)
AM040FXMDEH 100 kg 940 x 330 x 1,210
AM050FXMDEH 100 kg 940 x 330 x 1,210
AM060FXMDEH 103 kg 940 x 330 x 1,210
AM040FXMDGH 100 kg 940 x 330 x 1,210
AM050FXMDGH 100 kg 940 x 330 x 1,210
AM060FXMDGH 103 kg 940 x 330 x 1,210
