Electrical Parts List
6-3
MAIN PCB : DB93-05619B(cont.)
C202 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 SNA
C203 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 S
NA
C404 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 S
NA
C401 2203-000440 C-CER,CHIP 1nF,10%,50V,X7R,1608 1 S
NA
C405 2203-000440 C-CER,CHIP 1nF,10%,50V,X7R,1608 1 S
NA
C406 2203-000440 C-CER,CHIP 1nF,10%,50V,X7R,1608 1 S
NA
C104 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,1608 1 S
NA
C106 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,1608 1 S
NA
C402 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,1608 1 S
NA
C403 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,1608 1 S
NA
C407 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,1608 1 S
NA
C501 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,1608 1 S
NA
C801 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,1608 1 S
NA
C901 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,1608 1 S
NA
XC71 2301-001220 C-FILM,LEAD-PPF 100nF,10%,275V,BK,18x6x12,15 1 S
NA
XC72 2301-001220 C-FILM,LEAD-PPF 100nF,10%,275V,BK,18x6x12,15 1 S
NA
CR71 2301-001251 C-FILM,LEAD-PPF 1.2uF,10%,450Vac,BK,38x18x30,3 1 S
NA
C105 2401-000037 C-AL 470uF,20%,16V,GP,TP,8x11.5,5 1 S
NA
C103 2401-000151 C-AL 1000uF,20%,25V,GP,TP,10x20,5 1 S
NA
C601 2401-002300 C-AL 47?F,20%,50V,GP,TP,6.3x11,5mm 1 S
NA
C111 2401-003518 C-AL 6.8uF,20%,450V,GP,TP,10x16mm,5 1 S
NA
C112 2401-003518 C-AL 6.8uF,20%,450V,GP,TP,10x16mm,5 1 S
NA
L101 2702-001118 INDUCTOR-RADIAL 5000uH,10%,8.0x11.0mm 1 S
NA
XTAL51 2802-001179 RESONATOR-CERAMIC 4MHZ,0.5%,BK,8X3X5.5MM 1 S
NA
BZ61 3002-001129 BUZZER-PIEZO 85DB,-,-,2KHZ,- 1 S
NA
RY74 3501-001154 RELAY-MINIATURE 12Vdc,200mW,3000mA,1FormA,10mS,10mS 1 S
NA
RY71 3501-001169 RELAY-POWER 12VDC,0.9W,20000MA,SPST,20MS,10MS 1 S
NA
SS71 3502-000115 SSR 12Vdc,-,2A,1mS,1mS 1 S
NA
F701-1 3601-000263 FUSE-CARTRIDGE 250V,3.15A,TIME-LAG,GLASS,5x20mm 1 S
NA
F702 3601-001209 FUSE-RADIAL LEAD 250V,1A,TIME-LAG,-,8.5x8mm 1 S
NA
CN72 3711-000262 HEADER-BOARD TO CABLE 1WALL,3P,1R,7.92MM,STRAIGHT,SN,WHT 1 S
NA
CN44 3711-000879 HEADER-BOARD TO CABLE BOX,3P,1R,2.5mm,STRAIGHT,SN,BLU 1 S
NA
CN80 3711-000941 HEADER-BOARD TO CABLE BOX,4P,1R,2.5mm,STRAIGHT,SN 1 S
NA
CN71 3711-003404 HEADER-BOARD TO CABLE 1WALL,2P,1R,7.92mm,STRAIGHT,SN,BLU 1 S
NA
CN91 3711-004352 HEADER-BOARD TO CABLE BOX,15P,1R,2mm,STRAIGHT,SN,NTR 1 S
NA
CN43 3711-004379 HEADER-BOARD TO CABLE BOX,4P,1R,2mm,STRAIGHT,SN,NTR 1 S
NA
CN61 3711-004484 HEADER-BOARD TO CABLE BOX,5P,1R,2mm,STRAIGHT,SN,NTR 1 S
NA
ST11 DB26-00015A TRANS SWITCHING
-,JT1916-09,-,310V,FERRITE,-,EI1916,130KHZ,-
,1.65MH,-,-,-,-,SHIELD
1 S
NA
FT71 DB27-00017A COIL CHOKE
USAV-07153,UU1116,15.0mH,-25?~+85?,-,1.3ohm,-
,15mH,105,20*18mm,13,0.6,BK,-25?
1 S
NA
DB41-00526A PCB MAIN
VIVACE-PJT 9K/12K,CEM-3,2,1.0,T
1.6mm,160*140mm,-,2,-,-
1 S
NA
F701 DB61-00924A HOLDER-FUSE -,FH-51B,-,-,-,-,SSEC 1 SNA
IC04 DB91-00376A ASSY-MICOM INV-Vivace1,MB90F823, 80P, ROM 128K bytes 1 S
NA
DB93-04814A ASSY CONNECTOR WIRE FORTE1-PJT,UL1015 20AWG 1 S
NA
CN63 3711-000999 HEADER-BOARD TO CABLE BOX,5P,2.5mm,STRAIGHT,WHT 1 S
NA
CN21 DB93-04256A ASSY PCB SUB ASSY PCB COMM AC 1 S
A
Location No. Code No. Description Specification Q’ty SA/SNA
