Samsung Electronics
Electrical Parts List
SUB PCB : DB93-04256A
C301 2203-000440 C-CER,CHIP 1nF,10%,50V,X7R,1608 1 SNA
C302 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 SNA
C303 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 SNA
C701 2401-001428 C-AL 470uF,20%,50V,GP,TP,10x20,5 1 SNA
C702 2301-000141 C-FILM,LEAD-PEF 10nF,10%,630V,TP,16x11x7.5mm,5 1 SNA
C703 2301-000256 C-FILM,LEAD-PEF 4.7nF,10%,100V,TP,10x8.5x5.0mm 1 SNA
C704 2301-000256 C-FILM,LEAD-PEF 4.7nF,10%,100V,TP,10x8.5x5.0mm 1 SNA
C705 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
C706 2203-000444 C-CER,CHIP 1nF,10%,50V,X7R,2012 1 SNA
CN11 3711-006040 HEADER-BOARD TO BOARD NOWALL,10P,2R,2.54mm,ANGLE,AU,BLK 1 SNA
D701 0402-001213 DIODE-RECTIFIER MRA4005,600V,1A,SMC,TP 1 SNA
D702 0402-001213 DIODE-RECTIFIER MRA4005,600V,1A,SMC,TP 1 SNA
D703 0402-001213 DIODE-RECTIFIER MRA4005,600V,1A,SMC,TP 1 SNA
PC31 0604-001172 PHOTO-COUPLER TR,100-300,200mW,SOP,TP 1 SNA
PC32 0604-001172 PHOTO-COUPLER TR,100-300,200mW,SOP,TP 1 SNA
Q301 0504-001064 TR-DIGITAL DTC114EKA,NPN,200mW,10K/10K,SOT-23,TP 1 SNA
Q302 0504-001064 TR-DIGITAL DTC114EKA,NPN,200mW,10K/10K,SOT-23,TP 1 SNA
R301 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 1 SNA
R302 2007-000077 R-CHIP 470ohm,5%,1/10W,TP,1608 1 SNA
R303 2007-000084 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 1 SNA
R701 2003-000855 R-METAL OXIDE(S) 47Kohm,5%,3W,AA,TP,6x16mm 1 SNA
R702 2003-000855 R-METAL OXIDE(S) 47Kohm,5%,3W,AA,TP,6x16mm 1 SNA
R703 2003-002007 R-METAL OXIDE(S) 4.7Kohm,5%,2W,AF,TP,3.9x10mm 1 SNA
R704 2003-002007 R-METAL OXIDE(S) 4.7Kohm,5%,2W,AF,TP,3.9x10mm 1 SNA
R706 2007-000282 R-CHIP 100Kohm,5%,1/8W,TP,2012 1 SNA
R707 2007-000468 R-CHIP 1Kohm,5%,1/8W,TP,2012 1 SNA
ZD71 0403-000537 DIODE-ZENER 1N4749A,5%,1000mW,DO-41,TP 1 SNA
- DB41-00527A PCB SUB FORTE,CEM-3,2,1.0,T1.6,50x33mm,-,9,-,COMM AC 1 SNA
- DB93-04350B ASS’Y CONNECTOR WIRE-PCB AQV12FA,12K_In 1 SNA
Location No. Code No. Description Specification Q'TY SA/SNA
Remark
6-6
