26
SAMSUNG ELECTRONICS
No. Parts Procedure Remark
2 CONTORL IN 15)Unfasten a screw of the Ground wire
and pick up Temperature wires from
ASSY EVAP. (Use (+) Screw Driver.)
16) The CONTROL-IN is xed to HOLDER
PIPE by a hook bottom of the case as
shown in the last gure. (Please loosen
remaining connectors before detaching
CASE-CONTROL.
Caution:
When you separate the connector, pull
pressing the locking button.
17) Put down of the HOLDER PIPE and
push up the hook and lean side the case
as shown in gures.
To Next Page
