27
SAMSUNG ELECTRONICS
No. Parts Procedure Remark
3 TRAY DRAIN 18) To detach the TRAY DRAIN from the
main frame, pull the bottom of the TRAY
DRAIN and it leans toward to you as
shown in gures.
19) Pull out the Drain Hose.
