40
SAMSUNG ELECTRONICS
NO. Parts Procedure Remark
2 Fan
&
Motor
1) Detach the Nut Flange like
the picture on the right side.
(Turn clockwise because the
screw is left-handed.)
(Use Monkey Spanner.)
2) Detach the Fan Propeller.
3) Loosen 4 fixing screws to
detach the Motor.
(Use Monkey Spanner.)
4) Disconnect the wire
between Ass’y Control Out and
Motor.
5) Loosen fixing bolts and
detach the Bracket Motor
