SAMSUNG ELECTRONICS
NO. Parts Procedure
Remark
3 Assy
Control Out
1) To remove the Cover control
box : Pull the motor wire is
allow
sufficientspace as shown on the
right side and then remove the
screw.
2) Detach several connectors
from the Assy Control Out.
3) Detach several connectors
from the PCB of Assy Control
Out.
1) Release the refrigerant at
first.
2) Loosen ng screw on both
sides.
3) Disassemble the pipes in both
inlet and outlet with welding
torch.
4) Detach the Heat Exchanger.
To Next Page
