45
SAMSUNG ELECTRONICS
No. Parts Procedure Remark
2 Fan
&
Motor
1) Detach the Nut Flange like the picture
on the right side. (Turn clockwise
because the screw is left-handed.)
(Use Monkey Spanner.)
2) Detach the Fan Propeller.
3) Loosen 4 xing screws to detach the
Motor.
(Use Monkey Spanner.)
4) Disconnect the wire between Assy
Control Out and Motor.
5) Loosen xing bolts and detach the
Bracket Motor
