Samsung AR18TXFCAWKXEU - Assy Kit Code Db92-04842 J

53
SAMSUNG ELECTRONICS
5-5 ASSY KIT CODE DB92-04842J
Main materials list
No NAME CODE A unit Remark
1 ASSY-THERMAL GREASE 0205-000178 0.002 Kg
2 SCREW-MACHINE (TB) 6001-000722 2 EA
3 SCREW-TAPPING (CLAMP 4EA) 6002-000234 4 EA
4 SCREW-TAPPING (CLAMP 2EA, CASE 1EA) 6002-000239 3 EA
5 SCREW-TAPPING (PBA) 6002-000630 1 EA
6 SCREW-TAPPING (EARTH) 6009-001001 5 EA
7 ASSY-SCREW MACHINE (H/S??) DB91-00933A 3 EA
8 HOLDER-WIRE CLAMP DB61-00250A 2 EA
9 CASE CONTROL LOW (WW, SI,Q-480) DB61-06722A 1 EA
10 COVER CONTROL OUT (WW, SI) DB63-04234A 1 EA
11 PLATE CONTROL(N-SI) DB61-05897C 1 EA
12 SPRING DB81-00635A 2 EA
13 SEAL DB62-11637T 0.153 mm
14 LABEL DB98-34030A 1 EA
15 HEAT SINK DB62-13008A 1 EA
16 TERMINAL BLOCK DB65-00274A 1 EA
17 TERMINAL BLOCK DB37-00036A 1 EA
18 ASSY CONNECTOR WIRE-POWER DB93-16371A 1 EA
1
15
2
35
10
3
4
5
6
7
8
11
9
12
12
14
13
17
18
19
20
21
22
23
34
