Samsung AR18TXFCAWKXEU - Assy Kit Code Db92-04842 A

51
SAMSUNG ELECTRONICS
5-4 ASSY KIT CODE DB92-04842A
Main materials list
No NAME CODE A unit Remark
1 ASSY-THERMAL GREASE 0205-000178 0.002 G
2 SCREW-MACHINE (TB) 6001-000722 2 EA
3 SCREW-TAPPING[N-V2MD] (CLAMP) 6002-000231 2 EA
4 SCREW-TAPPING[N-V2MD] (CASE) 6002-000239 2 EA
5 SCREW-TAPPING (PBA) 6002-000630 1 EA
6 SCREW-TAPPING (EARTH) 6009-001001 4 EA
7 ASSY-SCREW MACHINE (H/S) DB91-00933A 3 EA
8 HOLDER-WIRE CLAMP DB61-02200A 1 EA
9 RUBBER DB67-01534A 1 EA
10 PLATE CONTROL UP DB61-06600A 1 EA
11 PLATE CONTROL LOW DB61-06713A 1 EA
12 PLATE CONTROL DB61-06715D 1 EA
13 COVER CONTROL UP DB63-03378A 1 EA
14 CASE CONTROL LOW DB61-06714A 1 EA
15 SPRING DB81-00635A 2 EA
16 LABEL DB98-34030A 1 EA
17 HEAT SINK DB62-13007A 1 EA
18 TERMINAL BLOCK DB65-00274A 1 EA
1
17
2
3
4
5
6
9
8
10
11
12
15
16
18
19
28
30
29
23
24
