2-2 Product Specifications
Model AR09TXFCAWK/EU AR12TXFCAWK/EU AR24TXEAAWK/EU AR09TXEAAWK/EU
Rating Mode Unit Wall-mounted Wall-mounted Wall-mounted Wall-mounted
Capacity
T1 Cool W 2500 3500 6500 2500
T3 Cool W - - - -
Heat W 3200 3500 7400 3200
Power Input
T1 Cool W 700 1220 1950 570
T3 Cool W - - - -
Heat W 840 940 2350 760
Current
T1 Cool A 3.6 5.6 8.8 3.4
T3 Cool A - - - -
Heat A 4 4.5 10.5 3.7
Efciency
EER W/W 3.57 2.87 3.33 4.39
- - - -
COP W/ W 3.81 3.72 3.15 4.21
Platform
IDU - QF1 QF1 QF3 QF2
ODU - N-V2MD N-V2MD Q-480 N-SI
Evap
Main - Φ7, 2R*9(10)S*591mm, H1.3, N.G.S, 1by2 Φ7, 2R*9(10)S*591mm, H1.3, N.G.S, 1by2
Φ7, ( 2R*10S+1R*4S )*825.5mm,
(H1.3+H1.3), N.G.S, 4by4
Φ7, 2R*10S*660mm, H1.3, N.G.S, 2by2
Sub - Φ7, 2R*5(6)S*591mm, H1.3, N.G.S : (Q-1-5) Φ7, 2R*5(6)S*591mm, H1.3, N.G.S : (Q-1-5)
Φ7, ( 2R*6S+1R*4S )*825.5mm,
(H1.3+H1.3), N.G.S : (Q-3-7)
Φ7, 2R*5(6)S*660mm, H1.3, N.G.S : (Q-2-1)
Cond
Main -
Φ7W, 2R*20(21)S*639/611mm,
Corrugate1.5, N.G.S, 4by4by2
Φ7W, 2R*20(21)S*639/611mm,
Corrugate1.5, N.G.S, 4by4by2
Φ7W, 2R*28S*906.8mm, Corrugate1.5,
N.G.S, 4by4by1
Φ7W, 2R*24S*850/825mm, Corrugate1.5,
N.G.S, 4by4by2
Sub - - - - -
Comp Model - UB1AR5090FE6 UB1AR5090FE6 UB9TK2150FE4 UB1AR5090FE6
Motor In
Code - DB31-00694A DB31-00694A DB31-00637A DB31-00636A
Name - FMH2031SSA FMH2031SSA RD-310-25-8B / SIC-37CVL-F127-2 RD-310-25-8A(AL) / SIC-41CVJ-F127-2
Motor Out
Code - DB31-00693A DB31-00693A DB31-00658D DB31-00642C
Name - ZKFP-30-8-222 ZKFP-30-8-222 FMDC531SSE / YMAP095AE01A1 RD-310-45-8B
Expansion Φ * L - EEV, Φ1.3 [029] EEV, Φ1.3 [029] EEV, Φ1.4 EEV Φ1.3
Refrigerant
type - R32
R32 R32 R32
charge g 700 g
700 g 1300 g 940 g
SVC Valve Liquid / Gas - 6.35 / 9.52 6.35 / 9.52 6.35 / 15.88 6.35/9.52
Tube Dis. / Suc. - 7.94 / 9.52 7.94 / 9.52 9.52 / 12.7 7.94/9.52
Power Cord - - - - 20*550
4-WAY V/V - 1 hp 1 hp 2 hp 1 hp
Power Supply V/Hz/Φ 220-240/50/1 220-240/50/1 220-240/50/1 220-240/50/1
Climate Class - T1 T1 T1 T1
NOISE
IDU UT,T dB 44 / 59 dB 44 / 59 dB 51 / 62 dB 43 / 57
ODU dB 54 / 65 dB 54 / 65 dB 60 / 68 dB 53 / 62
Net Size
(W*D*H)
IDU
mm
820*299*215 820*299*215 1065*311*301 889*299*215
ODU 660*475*242 660*475*242 880*310*648 950*290*375
Weight
IDU
kg
8.9 23 13 10.6
ODU 23 IDU 40.8 12.5
Operation range
Cooling
IDU 16 ˚C~32 ˚C 16 ˚C~32 ˚C 16 ˚C~32 ˚C 16 ˚C~32 ˚C
ODU -10 °C to 46 °C -10 °C to 46 °C -10 °C to 46 °C -10 °C to 46 °C
Heating
IDU 27 °C or less 27 °C or less 27 °C or less 27 °C or less
ODU -15 °C to 24 °C -15 °C to 24 °C -15 °C to 24 °C -15 °C to 24 °C
