58
SAMSUNG ELECTRONICS
Level Parts Code Design Loc Parts Description Spec. Quantity Unit
..1 0401-000132 AD901 DIODE-SWITCHING BAV99,75V,50mA,SOT-23,TP 1 PC
..1 0401-001099 D021 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP 1 PC
..1 0402-000324 BD151 DIODE-BRIDGE D3SB60,600V,4A,SIP-4,ST 1 PC
..1 0402-001192 D170 DIODE-RECTIFIER ES2D,200V,2A,SMB,TP 1 PC
..1 0402-001299 BD051 DIODE-BRIDGE TS25P05G,D25XB60,600V,25A,SIP-4,BK 1 PC
..1 0402-001427 D061 DIODE-RECTIFIER ES1D,200V,1A,DO-214AC,TP 1 PC
..1 0402-001669 D173 DIODE-RECTIFIER ES3D,200V,3A,DO-214AB(SMC),TP 1 PC
..1 0402-001741 D151 DIODE-RECTIFIER S1M,1000V,1A,SMA,TP 1 PC
..1 0402-001795 D051 DIODE-RECTIFIER US1M,1000V,1A,SMA,TP 1 PC
..1 0403-000461 ZD061 DIODE-ZENER
PTZ18A,16.8-19.1V,1000mW,SOD-
106(SMA)1W,TP,18V
1 PC
..1 0406-001204 TD300 DIODE-TVS SMBJ5.0CA,6.4/-/7.25V,600W,SMB 1 PC
..1 0501-000465 Q032 TR-SMALL SIGNAL
MMBT3904,NPN,350mW,SOT-
23,TP,30~300
1 PC
..1 0501-000467 Q181 TR-SMALL SIGNAL
MMBT3906,PNP,350mW,SOT-
23,TP,30~300
1 PC
..1 0502-001266 Q190 TR-POWER KTA1532T,PNP,900mW,TSM,TP,200/-/560 1 PC
..1 0505-000110 Q870 FET-SILICON
2N7002,N,60V,0.115A,7.5ohm,0.3W,S
OT-23
1 PC
..1 0505-003681 IC153 FET-SILICON A0N7264E,N,60V,28A,27.5W,DFN 3x3 EP 1 PC
..1 0506-000175 IC801 TR-ARRAY 2003,NPN,7,1000mW,SOP-16,TP,1000 1 PC
..1 0601-002423 LED812 LED
SMD(Top View),RED,WATER CLEAR,1.6
x1.5mm,3.2x1.6x1.1mm,1,130deg,11
2/180mcd,-55to+85C,639nm,75mW,-,-
,TP,INDICATOR
1 PC
..1 0601-002955 LED810 LED
SMD(Top View),YEL,WATER CLEAR,1.6x1.5
mm,3.2x1.6x1.1mm,1,130deg,18/60mcd,-
55to+85C,588nm,75mW,-,-,TR,INDICATOR
1 PC
..1 0601-002956 LED802 LED
SMD(Top View),GRN,WATER CLEAR,1.6x1.5
mm,3.2x1.6x1.1mm,1,130deg,18/35mcd,-
55to+85C,574nm,75mW,-,-,TR,INDICATOR
1 PC
..1 0604-001172 PC181 PHOTO-COUPLER TR,150-300,200mW,SOP,TP 1 PC
..1 0801-000393 IC301 IC-CMOS LOGIC
74HC86,OR GATE,SOP,14P,150
MIL,QUAD,TP,2.0/6.0V,0.26V,-
40to+85,180mW,4.2V,1uA,0.1uA,5.2mA
1 PC
..1 0903-002197 MIC501
IC-
MICROCONTROLLER
HART-I910Z,LQFP,64P,12x1
2mm,8MHz,TR,5V,600mW,-
40to+85C,12KB,128KB,Inverter SOC
1 PC
..1 0903-002203 MIC200
IC-
MICROCONTROLLER
HART-M320,MQFP,100P,20x14m
m,8MHz,TR,Plastic,5V,600 mW,-
40to+85C,24KB,384KB,Cortex-M3
1 PC
..1 1003-002940 IC061 IC-GATE DRIVER
SOIC,8P,5.0x4.0x1.75mm,Tape &
Reel,13.5/25,-55to+150C
1 PC
..1 1006-001325 IC300 IC-BUS TRANSCEIVER
SO,8P,4.9x3.8 mm,SINGLE,ST,PLASTIC,5V,-
40to+85C,1,1,1.5/5.0V
1 PC
..1 1107-002547 IC870 IC-NOR FLASH
W25Q16JVSSIQ,16Mbit,2Mbitx8,SO
P,8P,5.28x5.28x1.95mm,2.7~3.6V,-
40to+85C,50uA,TR
1 PC
6-3 ASSY MODULE- DB92-04837A
To Next Page
