37
■
Part’s List
C103 C-CERAMIC,DISC 2.2nF,20%,400V,Y5U,TP,12. 1
C702 C-FILM,MPPF 100nF,10%,275V,BK,18x6x12,15 1
CR71 C-FILM,MPPF 2000nF,+10-5%,450V,BK,38x18x 1
C701 C-FILM,MPEF 220NF,10%,275V,BK,26.5X8.5X1 1
RY71,72,74 RELAY-MINIATURE 12VDC,200MW,3000MA,1FORM 3
SS71 SSR 12Vdc,-,2A,1mS,1mS 1
IC04 IC MICOM S3C8469(SDIP) 1
IC02 IC-VOLT REGU KA7805A,TO-220AB,1A,0/125C, 1
TN11 TRANS 2UEW0.30/2UEW0.45,1.5KV,1KHz,-,7Pi 1
FT71 CHOKE-COIL LSA-05230P,AC250V,2A,30.5x22x3 1
BZ61 BUZZER CBE2220BA,STICK,-,-,-,-,-,-,- 1
F701 FUSE FST,250V,3.15A,20MM,VDE,50T-03 1
F701 HOLDER-FUSE FH-51H,7.5A,-,-,-,-,- 1
D101,102,103,104 DIODE-RECTIFIER 1N4007,1000V,1A,DO-41,TP 4
D105 DIODE-RECTIFIER UG2B,100V,2A,DO-204AC,TP 1
ZD12 DIODE-ZENER DIODE-ZENER;MTZ3.6A,3.6V,3.455-3.695V,50 1
ZD13 DIODE-ZENER DIODE-ZENER;MTZJ11B,11V,10.5-11.05V,500m 1
ZD11 DIODE-TVS DIODE-TVS;ST02D-200,185/200/215V,200W,DO 1
Q603 TR-SMALL SIGNAL TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92 1
Q401,601,602 TR-SMALL SIGNAL TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 3
Q901,902 TR-DIGITAL TR-DIGITAL;KSR2002,PNP,300MW,10K/10K,TO- 2
Q201 TR-DIGITAL TR-DIGITAL;KSR1002,NPN,300MW,10K/10K,TO- 1
PC11 PHOTO-COUPLER PHOTO-COUPLER;TR,50-600%,200mW,DIP-4,ST 1
PC12 PHOTO-COUPLER PHOTO-COUPLER;TR,20-300%,200mW,DIP-4,ST 1
IC01 IC-PWM CONTROLLER IC-PWM CONTROLLER;255,DIP,8P,300MIL,PLAS 1
VA71,72 VARISTOR 560V,2500A,17.5x7.5mm,TP 2
R405,406 R-CARBON 330ohm,5%,1/8W,AA,TP,1.8x3.2mm 2
R104,105 R-CARBON 220OHM,5%,1/4W,AA,TP,2.4X6.4MM 2
R101 R-CARBON 470OHM,5%,1/4W,AA,TP,2.4X6.4MM 1
R206,501,502,601,604,606,902 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 7
R201,207,208,401,403,408,603,605,608 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 9
R910,911,912,913 R-CARBON 3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM 4
R102,103 R-CARBON 330KOHM,5%,1/4W,AA,TP,2.4X6.4MM 2
R106,901 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2
R607 R-CARBON 560OHM,5%,1/4W,AA,TP,2.4X6.4MM 1
R402 R-CARBON 6.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1
R602 R-CARBON(S) 1KOHM,5%,1/2W,AA,TP,2.4X6.4M 1
R202,203 R-METAL OXIDE(S) 51Kohm,5%,2W,AA,TP,4x12 2
R404,407 R-METAL 6.8Kohm,1%,1/8W,AA,TP,1.8x3.2m 2
C203,204,401 C-CERAMIC,MLC-AXIAL 10nF,+80-20%,25V,Y5V 3
C404,903 C-CERAMIC,MLC-AXIAL 1nF,10%,50V,Y5P,TP,1 2
C102,104,107,109,114,116,117,118,201, C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5 14
202,402,403,501,901
C105 C-AL 1000uF,20%,25V,GP,TP,10x20,5 1
C601 C-AL 47uF,20%,50V,GP,TP,6.3x11,2.5 1
C108 C-AL 470uF,20%,25V,GP,TP,10x16,5 1
C101,110 C-AL 6.8uF,20%,450V,GP,TP,10x16mm,5 2
X501 RESONATOR-CERAMIC 4MHz,0.5%,TP,10.0x5.0x 1
F702 FUSE-RADIAL LEAD 250V,1A,TIME-LAG,-,8.5x 1
CN78 CONNECTOR-HEADER 1WALL,3P/5P,1R,3.96mm,S 1
CN71 CONNECTOR-HEADER 1WALL,3P/5P,1R,3.96mm,S 1
CN73 CONNECTOR-HEADER 1WALL,3P/5P,1R,3.96mm,S 1
CN91 CONNECTOR-HEADER BOX,10P,1R,2.5mm,STRAIG 1
CN43 CONNECTOR-HEADER BOX,3P,1R,2.5mm,STRAIGH 1
CN41 CONNECTOR-HEADER BOX,4P,1R,2.5mm,STRAIGH 1
CN61 CONNECTOR-HEADER BOX,6P,1R,2.5mm,STRAIGH 1
IC07 IC-MASK ROM 93LC56B,8BIT,-,DIP,8P,-,-,- 1
IC03 IC-RESET KA7533,DIP,-,-,-,-,- 1
IC06 IC-DRIVE KID65003AP,DIP,16P,STICK,TR-AR 2
L101 COIL CHOKE 5.0mH,-,8.0*11.0,-,-,PE-M10 1
WIRE-SO COPPER PI0.6,SN,T,52MM,TAPING_WI 35
PCB-MAIN PD-SH30ZC-00,FR-1,-,-,T1.6,W197 1
Location No. Description Specification Q’TY
AS18A9(0)RCF SM_E_15775 3/10/05 7:15 PM Page 37
