3.DisassemblyandReassembly
3.4.3.HVPSboard
1.Removetheleftcover.(Referto3.4.1.)2.Remove10screws.Unplugtheconnector.Andrelease
theHVPSboard.
3.4.4.OuterTemperatureSensor
1.Removetheleftcover.(Referto3.4.1)
2.Remove1screw.Unplugtheconnector.Andremove
thesensor.
Copyright©1995-2013SAMSUNG.Allrightsreserved.3-12
