Electrical Parts List
Samsung Electronics 7-3
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
....4 R109 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R110 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R115 2001-000645 R-CARBON;330KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R116 2001-000319 R-CARBON;120KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R117 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R202 2001-000689 R-CARBON;390KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R203 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R204 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R205 2001-000011 R-CARBON;75KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R206 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R207 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm
....4 R208 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R209 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R211 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R213 2001-000938 R-CARBON;68OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R214 2001-000490 R-CARBON;200OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R215 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R218 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R219 2004-001914 R-METAL;39Kohm,2%,1/8W,AA,TP,1.8x3.5mm
....4 R220 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R222 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R223 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R224 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R225 2001-000309 R-CARBON;110OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R227 2001-000739 R-CARBON;4.7MOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R228 2001-000739 R-CARBON;4.7MOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R229 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R230 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R301 2001-000016 R-CARBON(S);1OHM,5%,1/2W,AA,TP,2.4X6.4MM
....4 R302 2004-004366 R-METAL(S);1.3Kohm,1%,1/2W,AA,TP,2.5x6.5
....4 R303 2003-002070 R-METAL OXIDE;1ohm,5%,2W,AF,TP,3.9x10mm
....4 R304 2008-000253 R-FUSIBLE(S);0.47ohm,5%,1W,AF,TP,3.9x10m
....4 R305 2008-000253 R-FUSIBLE(S);0.47ohm,5%,1W,AF,TP,3.9x10m
....4 R306 2004-001369 R-METAL(S);1.2Kohm,1%,1/2W,AA,TP,2.4x6.4
....4 R307 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R308 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6.
....4 R313 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R314 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4M
....4 R315 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x
....4 R316 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x
....4 R402 2003-002178 R-METAL OXIDE(S);1Kohm,5%,2W,AG,TP,3.9x1
....4 R403 2003-001093 R-METAL OXIDE(S);12Kohm,5%,2W,AF,TP,3.9x
....4 R405 2001-001116 R-CARBON(S);27OHM,5%,1/2W,AA,TP,2.4X6.4M
....4 R407 2003-002209 R-METAL OXIDE(S);47Kohm,5%,2W,AG,TP,3.9X
....4 R408 2001-001037 R-CARBON(S);0.39OHM,5%,1/2W,AA,TP,2.4X6.
....4 R409 2001-000022 R-CARBON(S);33OHM,5%,1/2W,AA,TP,2.4X6.4M
....4 R411 2001-001114 R-CARBON(S);270OHM,5%,1/2W,AA,TP,2.4X6.4
....4 R413 2003-000532 R-METAL OXIDE(S);18ohm,5%,2W,AF,TP,4x12m
....4 R414 2001-001078 R-CARBON(S);15KOHM,5%,1/2W,AA,TP,2.4X6.4
....4 R420 2008-001110 R-FUSIBLE(S);68ohm,5%,2W,AG,TP,3.9X12mm
....4 R421 2008-001112 R-FUSIBLE(S);2.4ohm,5%,2W,AG,TP,3.9x12mm
....4 R423 2004-002011 R-METAL(S);110Kohm,1%,1/2W,AA,TP,2.4x6.4
....4 R424 2004-001402 R-METAL(S);6.8Kohm,1%,1/2W,AA,TP,2.4x6.4
....4 R501 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R501H 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7
....4 R502 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R502H 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7
....4 R503 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7
....4 R504 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA,TP,2.4X6.4
....4 R505 2008-000266 R-FUSIBLE(S);1ohm,5%,2W,AF,TP,3.9x10mm
....4 R506 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R510 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R511 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R512 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R601 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R602 2001-001015 R-CARBON;9.1KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R701 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R702 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R704 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R708 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R710 2001-000004 R-CARBON;200KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R713 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R715 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R719 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R720 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R721 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R803 2003-000994 R-METAL OXIDE(S);33Kohm,5%,2W,AF,TP,3.9x
....4 R804 2003-000994 R-METAL OXIDE(S);33Kohm,5%,2W,AF,TP,3.9x
....4 R805 2001-001170 R-CARBON(S);6.8OHM,5%,1/2W,AA,TP,2.4X6.4
....4 R806 2001-001108 R-CARBON(S);22KOHM,5%,1/2W,AA,TP,2.4X6.4
....4 R808 2001-000109 R-CARBON(S);470OHM,5%,1/2W,AA,TP,2.4X6.4
....4 R809 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6.
....4 R810 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6.
....4 R814 2008-001086 R-FUSIBLE(S);3.3ohm,5%,2W,AG,TP,3.9x12mm
....4 R815 2008-001086 R-FUSIBLE(S);3.3ohm,5%,2W,AG,TP,3.9x12mm
....4 R816 2003-002157 R-METAL OXIDE;220OHM,5%,2W,AG,TP,6X16MM
....4 R817 2004-004089 R-METAL(S);123Kohm,1%,1/2W,AA,TP,2.5x6.5
....4 R818 2004-001399 R-METAL(S);5.1Kohm,1%,1/2W,AA,TP,2.4x6.4
....4 R819 2004-001390 R-METAL(S);1Kohm,2%,1/2W,AA,TP,2.4x6.4mm
....4 R820 2004-001371 R-METAL(S);1.5Kohm,1%,1/2W,AA,TP,2.4x6.4
....4 R821 2001-001125 R-CARBON(S);300KOHM,5%,1/2W,AA,TP,2.4X6.
....4 R822 2004-001983 R-METAL(S);2.49Kohm,1%,1/2W,AA,TP,2.4x6.
....4 R823 2001-000037 R-CARBON(S);330OHM,5%,1/2W,AA,TP,2.4X6.4
....4 R824 2008-000294 R-FUSIBLE(S);33ohm,5%,2W,AF,TP,3.9x10mm
....4 R825 2008-000266 R-FUSIBLE(S);1ohm,5%,2W,AF,TP,3.9x10mm
....4 R827 2003-000652 R-METAL OXIDE(S);330ohm,5%,2W,AF,TP,4x12
....4 R828 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R829 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R830 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R831 2001-001192 R-CARBON(S);820OHM,5%,1/2W,AA,TP,2.4X6.4
....4 R832 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4M
....4 R834 2003-001040 R-METAL OXIDE(S);47Kohm,5%,2W,AF,TP,3.9x
....4 R840 2001-001122 R-CARBON(S);3.9KOHM,5%,1/2W,AA,TP,2.4X6.
....4 R841 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R843 2001-000019 R-CARBON(S);10OHM,5%,1/2W,AA,TP,2.4X6.4M
....4 R850 2001-001170 R-CARBON(S);6.8OHM,5%,1/2W,AA,TP,2.4X6.4
....4 R901 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R902 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R903 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R904 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R905 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm
....4 R906 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm
....4 R907 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R908 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R909 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R910 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R911 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R912 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R913 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R914 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R915 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R916 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R917 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R918 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R919 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R920 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R921 2001-000702 R-CARBON;39KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R922 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R923 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R924 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R925 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R926 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R927 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R928 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R933 2001-000628 R-CARBON;300OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R934 2001-000628 R-CARBON;300OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R935 2001-000674 R-CARBON;360OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R937 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R938 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 RX801S 2002-001011 R-COMPOSITION;3.3Mohm,5%,1/2W,AA,TP,3.7x
....4 RY801S 2002-001012 R-COMPOSITION;8.2Mohm,5%,1/2W,AA,TP,3.7x
....4 SW901 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
....4 SW902 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
....4 SW903 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
....4 SW904 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
....4 SW905 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
....4 T101 AA26-00025A TRANS-IF;7MG,-,-,-,10pF,-,58.35MHz,7.7x
....4 VX801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP
....4 X901 2801-003937 CRYSTAL-UNIT;12MHz,25ppm,28-AAM,30pF,30o
....4 Z202 2903-001040 FILTER-CERAMIC;TR,5.5/6.0/6.5MHz,-,1dB,-
..2 AA39-20010D LEAD CONNECTOR-ASSY;,1P,YFH800-01,S,400,
..2 AA65-30009A CLAMP-FBT;ABS,V0,BLK,-,-,- S.N.A
..2 AA65-30018A CLAMP-WIRE;NYLON-66,-,-,DATL-600,DONG-A, S.N.A
..2 AA65-30111A CLAMP-WIRE;NYLON,V0,WHT,1T 15MM,ALL MODE S.N.A
