ASSY CRT
1 * AA94-02410A ASSY CRT;A36QDT351X,+380mG,15INCH,BEAR,
..2 AA27-00002A MAGNET-CONVERGENCE;-,JH291-SC-OB,29.1MM
..2 AA63-60028A SPACER-DY;-,NEOPRENE,-,-,-,BLK,-,-,V0 W1
..2 AA27-00069A DEFLECTION-YOKE;-,DIF-1592CA,15,ST,2.0mH
..2 AA03-00146A CRT COLOR;-,A36QDT351X,+380mG,15inch,90,
ASSY CABINET FRONT
1 * AA91-00649C ASSY CABINET FRONT;,15K2,(SPK)SV012P MPP S.N.A
..2 KC+CF 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR
..2 KNOPOW AA61-60003J SPRING-CS;-,SUS304,0.5,OD6,H12,N7,-,-,-
..2 SPK+CF 6003-001022 SCREW-TAPTITE;RH,+,B,M3,L12,ZPC(BLK),SWR
..2 WIN+CF 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR
..2 AA65-30105A CLAMP-WIRE;NYLON 66,V2,NTR,15MM,ALL MODE S.N.A
..2 AA96-00652A ASSY SPEAKER;-,16OHM,3W,3001-001211,200M S.N.A
...3 3001-001211 SPEAKER;3W,16OHM,86DB,240HZ S.N.A
...3 AA39-20501A LEAD CONNECTOR-ASSY;,3(2),67096-003,REC,
..2 AA64-01697B DECORATION-POWER;15K2,PC,SEMI-VIOLET
..2 AA64-01696B KNOB CONTROL;15K2,ABS,G3676,SV104M+W971,
..2 AA64-01694B WINDOW REMOCON;15K2,ACRYL,CLR
..2 AA64-01693B KNOB POWER;15K2,ABS,G3676,SV104M+W971,HB
..2 AA64-01691D CABINET FRONT;15K2,SV012P MPP,HIPS,HB,G7 S.N.A
..2 AA61-40113A STOPPER-PCB;501H,HIPS,-,-,HB,NTR,-
ASSY CABINET
1 * AA90-00739B ASSY CABINET;15K2,CS15K2X/BWT S.N.A
..2 CB+CF AA60-10050T SCREW-TAPPING;-,SWRCH18A,M4,L20,RH,+,2S,
..2 CB+RJ AA60-10050T SCREW-TAPPING;-,SWRCH18A,M4,L20,RH,+,2S,
..2 CRT AA60-10050R SCREW-ASSY;-,SWRCH18A,M5,L31.5,HH,+,WC,-
..2 D-COIL AA65-30107A CLAMP-D,COIL;NYLON 66,V2,NTR,-,20~22 INC
..2 AA65-30008A CLAMP-CORD;PE,HB,BLK,-,-,-
..2 AA64-01692C CABINET BACK;15K2,HIPS,V2,BLK S.N.A
ASSY-POWER,CORD
1 * AA96-20109B ASSY-POWER,CORD;-,CP2/NO(4.0),H/C250,KKP
..2 3811-000401 WIRE-PVC CU;BCWA,300V,ROLL,17/0.16mm,#22 S.N.A
..2 AA39-10006X POWER-CORD;-,KKP419C,KLCE-2F,2.286MT,3P,
..2 AA61-20284A HOLDER;-,P-CORD,PP,VO,BLK,KE-002 S.N.A
ASSY ACCESSORY
1 * AA94-02746K ASSY ACCESSORY;CS15K2X/BWT,KS1A,RUSSIA S.N.A
..2 AA68-01402A MANUAL-GOOD WILL LETTER;,CIS,B5,1PAGE,A/ S.N.A
..2 AA68-01296A MANUAL USERS;-,-,RUS,-,W/P100(G),-,-,1,- S.N.A
..2 AA68-01120A MANUAL SERVICE;-,-,CIS,A4,6PAGE(FOLD),W/
..2 AA42-00003A ANT ROD;-,3S,720mm,ABS,UL/CSA,-
..2 AA26-90001C TRANS-MATCHING;-,300ohm/75ohm,PAL,40-890
REMOCON
1 * AA59-00198D REMOCON;,TM59,DREAM,24,L/GRAY,MONO,NON
Electrical Parts List
7-4 Samsung Electronics
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
