ASSY-A/V SIDE
1 * AA95-00944B ASSY-A/V SIDE;,DP - 21D8,KS1A,PAL,MONO A
..2 CE01 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
..2 CE04 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
..2 CE07 2202-000222 C-CERAMIC,MLC-AXIAL;3.3nF,20%,16V,Y5P,TP
..2 CN702 AA39-20461C LEAD CONNECTOR-ASSY;,11P,YBNH250-11,6709
..2 JE601 3722-000143 JACK-PHONE;1P(VER),3.4mm,AG,BLK,NO
..2 JR01 3722-001282 JACK-RCA;2P(3P),3.2mm,AU,BLK,-
..2 LE01 2701-000158 INDUCTOR-AXIAL;22uH,10%,2.5x3.4mm
..2 LE04 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
..2 PCB AA41-00393A PCB-SIDE AV;CS21D8,FR-1,1L,A,1.6T,245x24 S.N.A
..2 RE01 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M
..2 RE02A 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M
..2 AA98-60001Z ASSY-SUB,PART;SCT11D,A/V FRONT,PAL,- S.N.A
...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A
ASSY-CRT
1 * AA97-00215A ASSY-CRT;A51KQJ63X(H),+380MG,21,BARE,- S.N.A
..2 AA63-60028A SPACER-DY;-,NEOPRENE,-,-,-,BLK,-,-,V0 W1
..2 AA27-50004K DEFLECTION-YOKE;-,DST-2192ML(H1),ST-3,A5
..2 AA27-00002A MAGNET-CONVERGENCE;-,JH291-SC-OB,29.1MM
..2 AA03-10024T CRT-COLOR;-,A51KQJ63X(H),+380mG,21,90de
ASSY-SKD
1 * AA97-00978B ASSY-SKD;,CS2139S/AST,KS1A,KAZAHSTAN
..2 CLAMP AA65-30018A CLAMP-WIRE;NYLON-66,-,-,DATL-600,DONG-A, S.N.A
..2 LC801S AA27-00143A COIL DEGAUSSING;,35T,9OHM,21INCH,220V,20
..2 AA65-30111A CLAMP-WIRE;NYLON,V0,WHT,1T 15MM,ALL MODE S.N.A
..2 AA65-30018A CLAMP-WIRE;NYLON-66,-,-,DATL-600,DONG-A, S.N.A
..2 AA65-30009A CLAMP-FBT;ABS,V0,BLK,-,-,- S.N.A
ASSY-POWER,CORD
1 * AA96-20109B ASSY-POWER,CORD;-,CP2/NO(4.0),H/C250,KKP
..2 3811-000401 WIRE-PVC CU;BCWA,300V,ROLL,17/0.16mm,#22 S.N.A
..2 AA39-10006X POWER-CORD;-,KKP419C,KLCE-2F,2.286MT,3P,
..2 AA61-20284A HOLDER;-,P-CORD,PP,VO,BLK,KE-002 S.N.A
ASSY CABINET
1 * AA90-00691K ASSY CABINET;21D8,CS21D8C/NWT
..2 AV+CF 6002-000522 SCREW-TAPPING;TH,+,2,M4,L15,ZPC(BLK),SWR
..2 BACK AA60-00091A SPACER-FELT;-,FELT,150X10,-,-,BLK,T0.35, S.N.A
..2 CB+CF AA60-10050T SCREW-TAPPING;-,SWRCH18A,M4,L20,RH,+,2S,
..2 CB+JCK AA60-10050T SCREW-TAPPING;-,SWRCH18A,M4,L20,RH,+,2S,
..2 CRT+CF AA60-10050R SCREW-ASSY;-,SWRCH18A,M5,L31.5,HH,+,WC,-
..2 KC+CF 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR
..2 AA63-60004K SPACER-GUM,CRT;-,NTR RUBBER,-,-,-,BLK,T2 S.N.A
..2 AA64-01465A KNOB CONTROL;DP,29D8,-,-,-,AA64-01012B,- S.N.A
...3 AA64-01012B KNOB CONTROL;29D8,ABS,-,G3676,SV-907P,HB
..2 AA64-01796B CABINET BACK;DP,21D8,AA64-01422D(10.3KG)
...3 AA64-01422D CABINET BACK;21D8,HIPS,V2,BLK
..2 AA65-30008A CLAMP-CORD;PE,HB,BLK,-,-,-
..2 AA65-30107A CLAMP-D,COIL;NYLON 66,V2,NTR,-,20~22 INC
ASSY CABINET FRONT
1 * AA91-00617B ASSY CABINET FRONT;DP,21D8 CIS,(SPK)SV90
..2 POWER AA61-60003J SPRING-CS;-,SUS304,0.5,OD6,H12,N7,-,-,-
..2 SPK+CF 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR
..2 WIN+CF 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR
..2 AA64-70123B BADGE-BRAND;AL,R2000,SILVER,L=50,SAMSUNG
..2 AA65-30105A CLAMP-WIRE;NYLON 66,V2,NTR,15MM,ALL MODE S.N.A
..2 AA96-10146C ASSY SPEAKER;-,8ohm,5W,3001-000274,350/7 S.N.A
...3 3001-000274 SPEAKER;5W,8ohm,90dB,160Hz
...3 AA39-20505M LEAD CONNECTOR-ASSY;,4P,YSH025-04,REC,35
..2 AA64-01426B WINDOW REMOCON;21D8,PC,-,-,-,VOILET,-,-
..2 AA61-40113A STOPPER-PCB;501H,HIPS,-,-,HB,NTR,-
..2 AA64-01011B INDICATOR LED;29D8,ACRYL,-,CLR,-,-,- S.N.A
..2 AA64-01309K INLAY AV;PS SHEET,21D8,T0.3,S15A MONO S
..2 AA64-01423E CABINET FRONT;21D8 CIS,SV907P MDP,HIPS,H
..2 AA64-01425B KNOB POWER;21D8,ABS,-,G3676,SV907P,HB,-,
ASSY PACKING
1 * AA92-00365G ASSY PACKING;CS2085C/NWT,KS1A S.N.A
ASSY ACCESSORY
1 * AA97-00976D ASSY ACCESSORY;,CS2CD8C/NWT,KS1A,LITHUAI
..2 AA68-01010A MANUAL USERS;-,-,B5,-,W/P100(G),-,-,1,-,
..2 AA68-01120A MANUAL SERVICE;-,-,CIS,A4,6PAGE(FOLD),W/
..2 AA42-00003A ANT ROD;-,3S,720mm,ABS,UL/CSA,-
..2 AA26-90001C TRANS-MATCHING;-,300ohm/75ohm,PAL,40-890
REMOCON
1 * AA59-00198D REMOCON;,TM59,DREAM,24,L/GRAY,MONO,NON
Electrical Parts List
7-24 Samsung Electronics
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
