Electrical Parts List

Samsung Electronics 7-25

7-7 CS21S1S/NWT

Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark

ASSY PCB CHASSISPACK

1 * AA93-00070P ASSY PCB CHASSISPACK;,KS1A,CS21S1S/NWT,U

..2 AA90-00136E ASSY-PACKING,PCB;CHASSIS,KS1A,15A-1,S15A S.N.A

...3 AA61-30009A LOCKER-BAND,CLIP;-,SPC-1,-,-,18MM T0.5,- S.N.A

..2 AA94-03623M ASSY PCB MAIN(OPT);CS21S1S/NWT,KS1A,UKRA

...3 BOT AA39-00046E LEAD CONNECTOR-ASSY;,1P,JUMPER,BLK,150MM

...3 C801 2401-002213 C-AL;150uF,+30-10%,450V,GP,BK,25x35

...3 CN501 AA39-20620C LEAD CONNECTOR-ASSY;,9P,YBNH250-09,S,500

...3 D806 AA96-00243D ASSY H/S;-,BRIDGE,AA62-00045A,D06U20S,D S.N.A

....4 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A

....4 0402-001374 DIODE-RECTIFIER;FFPF06U20S,200V,6A,TO-22

....4 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR

....4 AA62-00045A HEAT SINK-PS;-,-,T1.0,-,-,DREAM,-,-,-,-,

...3 IC201S AA09-00125A IC MICOM;SPM802ERN5-0333,CS2039X,64P,3.

...3 IC301 AA96-00244A ASSY H/S;-,-,AA62-00046A,LA7840,- S.N.A

....4 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A

....4 1204-001483 IC-VERTICAL PROCESSO;LA7840,SIP,7P,708MI

....4 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR

....4 AA62-00046A HEAT SINK-PS;-,-,T1.0,-,D1(DREAM) 60X25X

...3 IC601 AA96-00244B ASSY H/S;-,-,AA62-00046A,TDA7266S,-

....4 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A

....4 1201-001308 IC-POWER AMP;7266,ZIP,15P,-,DUAL,26dB,PL

....4 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR

....4 AA62-00046A HEAT SINK-PS;-,-,T1.0,-,D1(DREAM) 60X25X

...3 JS701 3722-000497 JACK-PIN;4P,3.4MM,SN,BLK,-

...3 L805 AA27-10002L COIL-CHOKE;-,24UH,K,-,2A,-,24UH-K,10X10M

...3 Q401 0502-001160 TR-POWER;2SD2499,NPN,50000mW,TO-3P,BK,8

...3 SUB-PA AA98-00079A ASSY SUB PART;KS1A,MAIN(OPT),PAL,- S.N.A

....4 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A

...3 T444S AA26-00065A TRANS FBT;-,FSV-14A004C(S),14-22,125V

...3 AA99-30221U ASSY-PCB ROBOT; AA94-03623M ,ER S.N.A

....4 CR402S 2306-000188 C-FILM,MPPF;330nF,5%,400V,TP,26x19.5x11,

....4 CR410S 2303-001015 C-FILM,PPF;5.5nF,5%,1.6kV,TP,29x9.5x17,2

....4 CX801S 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm

....4 CY801S 2201-000446 C-CERAMIC,DISC;3.3nF,20%,400V,Y5U,TP,15x

....4 FP801S 3601-000281 FUSE-CARTRIDGE;250V,4A,TIME-LAG,GLASS,5.

....4 IC101 1204-001583 IC-IF CIRCUIT;U4468B,DIP,16P,-,PLASTIC,5

....4 IC501 AA96-50311A ASSY-H/S;-,VIDEO,AA62-30175D,TDA6107Q,- S.N.A

.....5 1201-001159 IC-VIDEO AMP;6107,ZSIP,9P,-,SINGLE,-,PLA

.....5 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR

.....5 AA62-30175D HEAT SINK-PS;-,SECC,T1.0,-,33X15X30 FT-2

....4 IC801S AA96-00242A ASSY H/S;-,-,AA62-30186B,KA5Q0765R,- S.N.A

.....5 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A

.....5 1203-001932 IC-PWM CONTROLLER;5Q0765,TO-220F,5P,185M

.....5 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW

.....5 AA62-30186B HEAT SINK-ES;-,-,-,SILVER,171J + COVER-H

....4 IC802 AA96-00245A ASSY H/S;-,-,AA62-00055A,KA7632,-

.....5 1203-001939 IC-POSI.FIXED REG.;7632,SIP,10P,-,PLASTI

.....5 AA62-00055A HEAT SINK-PS;-,-,T1.0,-,35*15*25,D1,-,-,

.....5 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR

....4 IC902 1103-001106 IC-EEPROM;C81DC,1028x8Bit,DIP,8P,300MIL,

....4 LD901 AA96-00555A ASSY LED GUIDE;-,-,UEX-LD-030,GREEN S.N.A

....4 LR401S AA27-00053A COIL-LINEARLITY;-,193uH,DR10X10 C:4.35,7

....4 LX801S AA29-30001D FILTER-LINE NOISE;SQ1913,-,6.0MH,0.8A,-

....4 NT802S 1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,T

....4 P803S 1404-001156 THERMISTOR-PTC;9OHM,+30%/-20%,220VRMS,27

....4 PC801S 0604-001038 PHOTO-COUPLER;TR,130-260%,200mW,DIP-4,ST

....4 RM901 AA59-60001U MODULE-REMOCON;-,ORC-50VF/SR-12V,38KHz,9

....4 SF101S 2904-000302 FILTER-SAW AV;38.9MHz,SIP5K,ST,15.4dB,B/

....4 SF102S 2904-001024 FILTER-SAW AV;38.9MHz,SIP5K,TP,18.3dB,PA

....4 SW801S 3403-001107 SWITCH-PUSH;250V,5A,DPST,-,KDC-A04

....4 T401 AA26-50001B TRANS-HORIZ.DRIVE;-,7.1mH,102uH,10-20uH,

....4 T801S AA26-00104A TRANS SWITCHING;CS21S5T,AC160~250V,EER35

....4 TU01S AA40-00077A TUNER;TECC0949PL35A(S),PAL,181CH,38.

....4 V999S 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,-

....4 AA99-10215T ASSY-PCB MAIN,AUTO; AA99-30221U ,V S.N.A

.....5 C101 2401-001101 C-AL;330uF,20%,16V,GP,TP,8x11.5,5

.....5 C103 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

.....5 C105 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V

.....5 C106 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V

.....5 C109 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5

.....5 C110 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5

.....5 C111 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V

.....5 C114 2201-000611 C-CERAMIC,DISC;0.056nF,5%,50V,NP0,TP,7x3

.....5 C115 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP

.....5 C119 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5

.....5 C120 2401-002075 C-AL;4.7uF,20%,50V,GP,TP,5x11,5

.....5 C121 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm

.....5 C203 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5

.....5 C206 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm

.....5 C207 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm

.....5 C208 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

.....5 C209 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5

.....5 C210 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

.....5 C211 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP

.....5 C212 2401-000647 C-AL;2.2uF,20%,50V,BP,TP,5x11,5

.....5 C213 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5

.....5 C214 2401-003102 C-AL;100uF,20%,10V,GP,TP,5x11,5

.....5 C215 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm

.....5 C216 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm

.....5 C217 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm,

.....5 C218 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

.....5 C219 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5

.....5 C220 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm

.....5 C221 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11,5

.....5 C222 2401-000758 C-AL;220nF,20%,50V,GP,TP,5x11,5

.....5 C223 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3

.....5 C224 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3

.....5 C225 2309-000138 C-FILM,PE-PPF;100nF,5%,50V,TP,20x16x8.5,

.....5 C226 2202-000829 C-CERAMIC,MLC-AXIAL;.82NF,10%,50V,Y5P,TP

.....5 C227 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm

.....5 C229 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5

.....5 C230 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m

.....5 C233 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm

.....5 C234 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm,

.....5 C248 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm

.....5 C301 2305-000285 C-FILM,MPEF;220NF,5%,100V,TP,10.5X5.5X15

.....5 C302 2201-000259 C-CERAMIC,DISC;0.18nF,10%,500V,Y5P,TP,5.

.....5 C303 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5.

.....5 C304 2401-002288 C-AL;470uF,20%,25V,WT,TP,10x20,5

.....5 C305 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5.

.....5 C306 2401-002288 C-AL;470uF,20%,25V,WT,TP,10x20,5

.....5 C307 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5

.....5 C308 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5

.....5 C309 2301-000254 C-FILM,PEF;39nF,5%,50V,TP,7.5x3.5x6.5mm,

.....5 C312 2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5

.....5 C403 2401-000560 C-AL;1uF,20%,160V,GP,TP,6.3x11,5

.....5 C406 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5

.....5 C407 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm

.....5 C408 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.

.....5 C420 2301-001065 C-FILM,MPPF;47nF,5%,630V,TP,19x15.5x7,7.

.....5 C501 2201-000192 C-CERAMIC,DISC;0.01nF,0.25pF,500V,NP0,TP

.....5 C502 2301-000213 C-FILM,PEF;220nF,5%,250V,TP,21.5x11,7.5

.....5 C503 2201-000723 C-CERAMIC,DISC;4.7nF,20%,3KV,Y5U,TP,16x5

.....5 C504 2401-001232 C-AL;4.7uF,20%,250V,GP,TP,10x12.5,5

.....5 C505 2202-000825 C-CERAMIC,MLC-AXIAL;680pF,10%,50V,Y5P,TP

.....5 C506 2401-000430 C-AL;10uF,20%,250V,GP,TP,10x16mm,5m

.....5 C601 2401-001998 C-AL;1000uF,20%,25V,GP,TP,10x20,5mm

.....5 C602 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5

.....5 C603 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5

.....5 C605 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm

.....5 C606 2301-000289 C-FILM,PEF;5.6nF,5%,50V,TP,7x6x3,5

.....5 C607 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5

.....5 C610 2301-000289 C-FILM,PEF;5.6nF,5%,50V,TP,7x6x3,5

.....5 C702 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP

.....5 C703 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP

.....5 C704 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP

.....5 C705 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5

.....5 C706 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5

.....5 C707 2301-000204 C-FILM,PEF;2.7nF,5%,50V,TP,7.4x3.9x13mm,

.....5 C708 2401-000471 C-AL;10uF,20%,50V,BP,TP,5x11,5mm
