Reference Information
Samsung Electronics 2-5
SPEC
VDP3108B
VDP3112B
VDP3120B
VDP3132Y
VDP3140D
FUNCTION
50Hz Basic
50Hz, 2H Comb Filtr
50Hz, 2H Comb Filter, Horizontal Scaler
50Hz, 2H Comb Filter, DVD Input
100Hz
REMARK
Table 2-3-1 VIDEO IC (IC201S)
SPEC
MSP3400D
MSP3410D
MSP3411G
FUNCTION
Multistandard, A2 Stereo
Multistandard, A2 Stereo, Nicam
Multistandard, A2 Stereo, Nicam, Vitual Dolby
REMARK
SPEC
TDA7297
FUNCTION
15W x 2CH, 10W x 2CH
REMARK
SPEC
TCLS3101PD09A(S)
TCPS3001PD09D(S)
TCPS3001PD09E(S)
FUNCTION
CS with LNA Function
CS
CS
REMARK
Main
India
SPEC
TCPS3000PC09B(S)
FUNCTION
CS
REMARK
Sub
TCPS3001PD09A(S) is out-of-date, TCPS3001PD09D(S) which is up-to-date has the same function.
Table 2-3-2 SOUND IC (IC601)
Table 2-3-3 SOUND AMP (IC602)
Table 2-3-4 1’st TUNER (TU01S)
Table 2-3-5 2’nd TUNER (TU02S)
