ASSY PCB MAIN(OPT)
* AA94-02574GASSY PCB MAIN(OPT);CS29A5WT8X/XSG,KS3A,U
C407 2301-001338 C-FILM,MPE-PPF;0.68nF,5%,1.6kV,TP,28x7x1
C820 2401-003076 C-AL;3300uF,20%,50V,WP,BK,18x35.5mm
C-BLOC AA26-00069ATRANS FBT;FUJ-29C002C(S),DREAM3,4,-,-,-,
CLAMP AA65-30018ACLAMP-WIRE;NYLON-66,-,-,DATL-600,DONG-A,
CLAMP AA65-30104CCLAMP-WIRE;NYLON 66,V2,NTR,W1 Z4,ALL MOD
CLAMP AA65-30105CCLAMP-WIRE;ALL MODEL,NYLON 66,V2,NTR,5MM
CLAMP AA65-30109ACLAMP-FBT;NYLON-66,V2,BLK,-,-,-
CLAMP AA65-30110ACLAMP-WIRE;NYLON 66,V2,BLK,PAL TVI,ALL M
D-COIL AA27-20002QCOIL-DEGAUSSING;-,29,14ohm,70T,L3300,E
IC901 AA09-00041AIC-MCU;SDA555X-OTP,SDA555X-OTP,-,-,52
IC903 1203-001944 IC-POSI.FIXED REG.;78RM33,TO-220,3P,-,PL
JA701 3722-001333 JACK-RCA;9P,3.2mm,NI,BLK,-
L402 AA27-00067ACOIL HORIZ. WIDTH;-,240uH,YL9N 12x20 C:6
L403 AA27-00014ACOIL-LINEARLITY;-,27UH,YL-81 DR15X18,-,-
L405 AA27-00057ACOIL HORIZ. WIDTH;-,10mH,YL-9N 15x27.5 C
L408 AA27-00056ACOIL HORIZ. WIDTH;-,600uH,YL9N 15x27.5 C
L808 AA27-10002L COIL-CHOKE;-,24UH,K,-,2A,-,24UH-K,10X10M
T444S AA26-00071ATRANS FBT;FUJ-29C007(S),W32,2.9mH,-,-,-,
T801S AA26-00046ATRANS SWITCHING;-,-,-,AC90~260V,DC135/16
TU01S AA40-00060ATUNER-F/S;TCPS3001PD09D(S),-,PAL-M(NTSC)
TUBE AA39-00108ALEAD CONNECTOR-ASSY;-,-,-,-,-,-,-,-,-,GR
AA39-20010CLEAD CONNECTOR-ASSY;-,YFH800-01,S,1P,600
AA65-30010ACLAMP-WIRE;NYLON-66,V0,NTR,-,-,-
AA65-30110ACLAMP-WIRE;NYLON 66,V2,BLK,PAL TVI,ALL M
AA95-00561AASSY-DYNAMIC FOCUS;-,29A6,KS3A,PAL,-,-
CH01 2401-000832 C-AL;220uF,20%,25V,GP,TP,8x11.5,5
CH02 2401-002009 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
CH03 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
CH04 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
CH05 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
CH06 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
CH07 2306-000327 C-FILM,MPPF;6.3nF,3%,1.6KV,TP,28.5x18x10
CH10 2303-000128 C-FILM,PPF;12nF,5%,1.6KV,BK,31x21x14,25m
CNH01 AA39-20566CLEAD CONNECTOR-ASSY;-,-,-,-,-,-,-,-,-,YB
ICH01 1201-000191 IC-OP AMP;4558,DIP,8P,300MIL,DUAL,20V/mV
LH01 AA26-00011ATRANS-DUMMY;-,3.5MH,EE2834,-,BK
LH02 AA27-40003J COIL-HORIZ.WIDTH;-,3mH,ER14 20,PI0.35,ST
PCB AA41-00152CPCB-DOUBLE FOCUS;CW29A6VN8X/XEF,FR-1,1L,
QH01 0502-000442 TR-POWER;2SC4636RB,NPN,2W,TO-220,ST,10-
QH02 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
QH03 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
QH04 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
RH01 2001-001165 R-CARBON(S);56OHM,5%,1/2W,AA,TP,2.4X6.4M
RH02 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RH03 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RH04 2001-001144 R-CARBON(S);4.7KOHM,5%,1/2W,AA,TP,2.4X6.
RH05 2001-001108 R-CARBON(S);22KOHM,5%,1/2W,AA,TP,2.4X6.4
RH06 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
RH07 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
RH08 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
RH09 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RH10 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RH11 2001-001107 R-CARBON(S);220ohm,5%,1/2W,AA,TP,2.4x6.4
RH12 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RH13 2001-001139 R-CARBON(S);39KOHM,5%,1/2W,AA,TP,2.4X6.4
RH14 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RH15 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RH16 2001-001078 R-CARBON(S);15KOHM,5%,1/2W,AA,TP,2.4X6.4
RH17 2001-001144 R-CARBON(S);4.7KOHM,5%,1/2W,AA,TP,2.4X6.
RH18 2001-001163 R-CARBON(S);560OHM,5%,1/2W,AA,TP,2.4X6.4
RH19 2001-000109 R-CARBON(S);470OHM,5%,1/2W,AA,TP,2.4X6.4
RH20 2003-002193 R-METAL OXIDE(S);33Kohm,5%,2W,AG,TP,3.9X
RH21 2003-002193 R-METAL OXIDE(S);33Kohm,5%,2W,AG,TP,3.9X
RH22 2003-002193 R-METAL OXIDE(S);33Kohm,5%,2W,AG,TP,3.9X
RH23 2001-001055 R-CARBON(S);1.8KOHM,5%,1/2W,AA,TP,2.4X6.
RH28 2008-001113 R-FUSIBLE(S);0.22ohm,10%,2W,AG,TP,3.9x12
WIRE1 AA39-20010ALEAD CONNECTOR-ASSY;-,YFH800-01,S,1P,200
WIRE3 AA39-20061CLEAD CONNECTOR-ASSY;-,YFH800-03,S,3P,200
AA95-00683AASSY-PCB,VIDEO S/W;-,29A6,KS3A,PAL,-,-
CNS01 3711-002704 CONNECTOR-HEADER;NOWALL,6P,1R,2.5mm,ANGL
CNS02 3711-002706 CONNECTOR-HEADER;NOWALL,8P,1R,2.5mm,ANGL
CS01 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
CS02 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
CS03 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
CS04 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
CS05 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
CS06 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
CS07 2401-002009 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
CS08 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
ICS01 1001-001114 IC-VIDEO SWITCH;TEA6425,VIDEO SWITCH ,DI
LS01 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
PCB AA41-00153DPCB-VIDEO SWITCH;CS29A6,FR-1,1L,D,1.6T,2
QS01 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
QS02 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
QS03 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
RS01 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
RS02 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
RS03 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RS04 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
RS05 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RS06 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
RS07 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RS10 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RS11 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AA95-00700AASSY PCB CRT;-,KS3A,29A6,-,PAL
1P1 AA39-20010DLEAD CONNECTOR-ASSY;-,YFH800-01,S,1P,400
1P2 AA39-20010DLEAD CONNECTOR-ASSY;-,YFH800-01,S,1P,400
C405 2306-000330 C-FILM,MPPF;7.7nF,3%,1.6KV,TP,28.5x18.5x
C406 2306-000330 C-FILM,MPPF;7.7nF,3%,1.6KV,TP,28.5x18.5x
C423 2301-001192 C-FILM,MPPF;820nF,5%,400V,TP,29x18.5x25.
C426 2306-000204 C-FILM,MPPF;430nF,5%,400V,TP,26x20.5x12.
C501 2201-000247 C-CERAMIC,DISC;0.015nF,5%,50V,NP0,TP,5x3
C502 2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
C503 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
C505 2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
C506 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
C507 2201-000247 C-CERAMIC,DISC;0.015nF,5%,50V,NP0,TP,5x3
C508 2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
C509 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
C510 2401-001563 C-AL;47uF,20%,400V,GP,TP,16x25,7.5
C511 2401-001232 C-AL;4.7uF,20%,250V,GP,TP,10x12.5,5
C512 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
C513 2201-002063 C-CERAMIC,DISC;10nF,+80-20%,3KV,Y5V,TP,1
C514 2401-000430 C-AL;10uF,20%,250V,GP,TP,10x16mm,5m
C515 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
C516 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
C518 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
C519 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
C520 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
C521 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
C522 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
C523 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
C526 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
C815 2401-003026 C-AL;330uF,20%,200V,GP,ST,22x35,10
CF01 2201-000179 C-CERAMIC,DISC;10nF,10%,50V,Y5V,TP,6.5x3
CF02 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
Samsung Electronics 7-1
Electrical Parts List
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
7. Electrical Parts List
7-1 CS29A5WT8X/XSG
