CF03 2201-000376 C-CERAMIC,DISC;0.22nF,5%,50V,SL,TP,6.3x3
CF04 2201-000653 C-CERAMIC,DISC;0.068nF,5%,50V,SL,TP,5x3,
CF05 2301-000261 C-FILM,PEF;4.7nF,5%,100V,TP,10.5x12.5x6.
CF06 2201-000516 C-CERAMIC,DISC;4.7nF,+100-0%,500V,Y5U,TP
CF07 2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
CF08 2201-000604 C-CERAMIC,DISC;0.056nF,+100-0%,500V,SL,T
CF10 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
CF11 2401-000927 C-AL;22uF,20%,250V,GP,TP,13x20,5
CF12 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
CF14 2401-000832 C-AL;220uF,20%,25V,GP,TP,8x11.5,5
CG01 2401-000832 C-AL;220uF,20%,25V,GP,TP,8x11.5,5
CG02 2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5
CG03 2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm
CG04 2401-000832 C-AL;220uF,20%,25V,GP,TP,8x11.5,5
CN501 3711-002641 CONNECTOR-HEADER;BOX,10P,1R,2.54mm,STRAI
CN501A 3711-002641 CONNECTOR-HEADER;BOX,10P,1R,2.54mm,STRAI
CN501E AA39-20025F LEAD CONNECTOR-ASSY;-,67096-010,S,10P,50
CN502A 3711-002646 CONNECTOR-HEADER;BOX,7P,1R,2.5mm,STRAIGH
CN502E AA39-20029KLEAD CONNECTOR-ASSY;-,67096-007,S,7P,400
CN902 3711-003043 CONNECTOR-HEADER;BOX,4P,1R,2.5mm,STRAIGH
CNF01 3711-002642 CONNECTOR-HEADER;BOX,3P,1R,2.5MM,STRAIGH
CNG01 3711-002643 CONNECTOR-HEADER;BOX,4P,1R,2.5MM,STRAIGH
CX801S 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm
CY802S 2201-002002 C-CERAMIC,DISC;4.7nF,20%,400V,Y5U,TP,16x
D502 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D507 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
D508 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
D509 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
D510 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
D511 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
D512 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
D801S 0402-000549 DIODE-BRIDGE;RBV606,600V,6A,-,BK H/SINK
DF01 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
DF02 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
DF03 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
DF04 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
DG01 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
DZ503 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D
DZ504 0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D
DZ505 0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D
DZF01 0403-001039 DIODE-ZENER;MA2560,56V,52-60V,1W,DO-41,T
DZF02 0403-001039 DIODE-ZENER;MA2560,56V,52-60V,1W,DO-41,T
FP801S 3601-000297 FUSE-CARTRIDGE;250V,5A,TIME-LAG,GLASS,5.
HC401 0402-001296 DIODE-RECTIFIER;FMP-3FU,1.5KV,5A,TO-3PF, H/SINK
HC401 0502-001136 TR-POWER;KSD5703,NPN,70W,TO-3PF,ST,8- H/SINK
HC801 0402-000233 DIODE-RECTIFIER;FML-G12S,200V,5A,-,- H/SINK
HC801 0402-001230 DIODE-RECTIFIER;FMG-G2CS,1000V,3A,TO-220 H/SINK
HC801 1203-001006 IC-VOLTAGE REGULATOR;78R05,TO-220F,4P,-, H/SINK
IC201S 1204-001633 IC-VIDEO PROCESS;VDP3112B-C3,DIP,64P,709
IC301 1204-000517 IC-VERTIVAL DEF.;LA7845,SIP,7P,-,PLASTIC H/SINK
IC401 1202-000103 IC-VOLTAGE COMP.;393,DIP,8P,300MIL,DUAL,
IC501 1201-001131 IC-VIDEO AMP;6111,SIP,9P,-,SINGLE,-,PLAS H/SINK
IC502 1201-001131 IC-VIDEO AMP;6111,SIP,9P,-,SINGLE,-,PLAS H/SINK
IC503 1201-001131 IC-VIDEO AMP;6111,SIP,9P,-,SINGLE,-,PLAS H/SINK
IC601 1204-001661 IC-SOUND PROCESSOR;MSP3411G-A2,DIP,52P,-
IC602 1201-001064 IC-POWER AMP;7297,ZIP,15P,-,DUAL,32DB,PL H/SINK
IC801S 1203-001482 IC-PWM CONTROLLER;3S1265R,TO-3P,5P,210,P H/SINK
IC803 1203-001697 IC-VOLTAGE REGULATOR;78R08,TO-220,4P,-,P
IC804 1203-000284 IC-POSI.FIXED REG.;7806,TO-220,3P,-,PLAS H/SINK
IC902 1103-001171 IC-EEPROM;24L161,16KBIT,DIP,8P,300MIL,10
ICG01 1201-000191 IC-OP AMP;4558,DIP,8P,300MIL,DUAL,20V/mV
JA501 3722-001503 JACK-PIN;1P,1PI,NI,RED,SCR-JACK
L501 2701-000178 INDUCTOR-AXIAL;33uH,10%,3x7mm
L503 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
L504 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
L505 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
LF01 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
LF02 2701-000112 INDUCTOR-AXIAL;100uH,10%,3x7mm
LF04 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
LF05 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
LX801S AA29-00012AFILTER LINE NOISE;CS29A6PF8X/HAC,-,0.1MA
NT802S 1404-001045 THERMISTOR-NTC;4.7OHM,15%,2900K,35.0MW,T
PC801S 0604-001038 PHOTO-COUPLER;TR,130-260%,200mW,DIP-4,ST
PCB AA41-00210CPCB-CRT;CS29A6,FR-1,1L,C,1.6T,330x245,
PT801S 1404-000002 THERMISTOR-PTC;9ohm,20%,-,-,TR,RECT,-
Q502 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
Q503 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
Q504 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
QF01 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
QF02 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
QF03 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1W,TO-92L,
QF04 0502-000153 TR-POWER;2SC2344-D,NPN,1.2W,TO-220,-,60 H/SINK
QF05 0502-000131 TR-POWER;2SA1011-D,PNP,1.2W,TO-220,-,60 H/SINK
QG01 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
QG02 0502-000244 TR-POWER;KSA940,PNP,1.5W,TO-220,-,40-14
QG03 0502-001007 TR-POWER;KSC2073-H2,NPN,25W,TO-220,ST,6
R501 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R502 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6.
R503 2001-000085 R-CARBON(S);100KOHM,5%,1/2W,AA,TP,2.4X6.
R504 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R505 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7
R506 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R507 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6.
R508 2001-000085 R-CARBON(S);100KOHM,5%,1/2W,AA,TP,2.4X6.
R509 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R510 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7
R511 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R512 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6.
R513 2001-000085 R-CARBON(S);100KOHM,5%,1/2W,AA,TP,2.4X6.
R515 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7
R517 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA,TP,2.4X6.4
R518 2003-002171 R-METAL OXIDE(S);150ohm,5%,2W,AG,TP,3.9x
R519 2002-001009 R-COMPOSITION;2.7Kohm,10%,1/2W,AA,TP,3.7
R521 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R522 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R523 2008-000255 R-FUSIBLE(S);1.5ohm,5%,1W,AA,TP,3.9x10mm
R526 2004-000500 R-METAL;2.7Kohm,1%,1/8W,AA,TP,1.8x3.2m
R527 2004-000433 R-METAL;1Kohm,1%,1/8W,AA,TP,1.8x3.2mm
R539 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R542 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R543 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R544 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R546 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RF02 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
RF03 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
RF04 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
RF05 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RF06 2001-000989 R-CARBON;820KOHM,5%,1/8W,AA,TP,1.8X3.2M
RF07 2001-000904 R-CARBON;620OHM,5%,1/8W,AA,TP,1.8X3.2MM
RF08 2001-000313 R-CARBON;11KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RF09 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
RF10 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
RF11 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
RF12 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
RF13 2001-001179 R-CARBON(S);68KOHM,5%,1/2W,AA,TP,2.4X6.4
RF14 2001-001071 R-CARBON(S);12KOHM,5%,1/2W,AA,TP,2.4X6.4
RF15 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,TP,2.4X6.4
RF16 2001-001179 R-CARBON(S);68KOHM,5%,1/2W,AA,TP,2.4X6.4
RF17 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,TP,2.4X6.4
RF18 2003-000458 R-METAL OXIDE(S);100ohm,5%,2W,AF,TP,4x12
RF19 2003-001023 R-METAL OXIDE(S);120ohm,5%,2W,AF,TP,3.9x
RF20 2003-002214 R-METAL OXIDE(S);680ohm,5%,2W,AG,TP,3.9x
RF21 2003-002214 R-METAL OXIDE(S);680ohm,5%,2W,AG,TP,3.9x
RF22 2003-002214 R-METAL OXIDE(S);680ohm,5%,2W,AG,TP,3.9x
RF23 2003-000746 R-METAL OXIDE(S);56ohm,5%,2W,AF,TP,4x12m
RF24 2003-000746 R-METAL OXIDE(S);56ohm,5%,2W,AF,TP,4x12m
RF25 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x
RG01 2004-001397 R-METAL(S);4.7Kohm,1%,1/2W,AA,TP,2.4x6.4
RG02 2004-002022 R-METAL(S);51Kohm,1%,1/2W,AA,TP,2.4x6.4m
RG03 2004-001987 R-METAL(S);4.3Kohm,1%,1/2W,AA,TP,2.4x6.4
RG04 2004-002022 R-METAL(S);51Kohm,1%,1/2W,AA,TP,2.4x6.4m
RG05 2001-001163 R-CARBON(S);560OHM,5%,1/2W,AA,TP,2.4X6.4
RG06 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,TP,2.4X6.4
RG07 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,TP,2.4X6.4
RG08 2001-001163 R-CARBON(S);560OHM,5%,1/2W,AA,TP,2.4X6.4
RL801S 3501-001040 RELAY-POWER;12VDC,500mW,10A,1FormA,15mS,
SG501 AA27-00084ACOIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
SG502 AA27-00084ACOIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
SG503 AA27-00084ACOIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
SG504 AA27-00084ACOIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
T401 AA26-50001L TRANS-HORIZ.DRIVE;-,29mH,133uH,4.5uH,EI2
VA999 3704-001032 SOCKET-CRT;8P,29PI,35.5PI,AU30U
Electrical Parts List
