Samsung CS29A6WT8X/BWT - Page 36

AA99-10179YASSY-PCB MAIN,AUTO; AA99-30184M ,V
D201 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D202 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D207 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D208 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D209 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D210 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D211 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D601 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D602 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D804 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D906 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
DZ402 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D909 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D412 0402-000010 DIODE-RECTIFIER;RGP15G,400V,1.5A,DO-204A
D403 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D406 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D407 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D808 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D810 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D811 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D907 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D405 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1.5A,DO-15L
D408 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1.5A,DO-15L
D402 0402-000534 DIODE-RECTIFIER;RG10V,400V,1.2A,DO-201,T
D413 0402-000537 DIODE-RECTIFIER;RH1A,600V,0.6A,DO-204AC
D401 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5A,-,TP
D404 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5A,-,TP
D409 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5A,-,TP
D301 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
D411 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
D803 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
D816 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
D801 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20
DZ201 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ202 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ601 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ603 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ802 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ806 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ902 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ903 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ904 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ905 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ906 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ907 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ602 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500
DZ306 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V,1W,DO-41,T
DZ804 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V,1W,DO-41,T
DZ808 0403-000719 DIODE-ZENER;MTZJ7.5B,7.5V,7.07-7.45V,500
DZ803 0403-001167 DIODE-ZENER;MTZJ30D,30V,29.02-30.51V,500
DZ305 0403-001221 DIODE-ZENER;UZ39BSB,35.36-37.19V,500MW,D
DZ203 0403-001321 DIODE-ZENER;MTZJ6.8C,6.66-7.01V,500mW,DO
DZ801 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500mW,DO
DZ401 0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D
DZ302 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,D
DZ303 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,D
DZ304 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,D
D203 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
D204 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
D205 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
D206 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
D901 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
D902 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
D903 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
D904 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
D905 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
Q802 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1W,TO-92L,
Q201 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q202 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q203 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q204 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q601 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q701 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q901 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q902 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q903 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q904 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q905 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q906 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q908 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q402 0502-001007 TR-POWER;KSC2073-H2,NPN,25W,TO-220,ST,6
Q909 0505-000109 FET-SILICON;2N7000,N,60V,200mA,5ohm,400m
Q910 0505-000109 FET-SILICON;2N7000,N,60V,200mA,5ohm,400m
Q404 0505-000156 FET-SILICON;IRF620,N,200V,5A,0.8ohm,50W,
DZ805 1203-001217 IC-POSI.ADJUST REG.;431,TO-92,3P,4.58MIL
IC904 1203-001943 IC-VOL. DETECTOR;7025,TO-92,3P,-,PLASTIC
VP801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP
VX801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP
R223 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
R248 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
R249 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
R250 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
R911 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
R303 2001-000016 R-CARBON(S);1OHM,5%,1/2W,AA,TP,2.4X6.4MM
R412 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,TP,2.4X6.4M
R809 2001-000022 R-CARBON(S);33OHM,5%,1/2W,AA,TP,2.4X6.4M
R411 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4
R825 2001-000066 R-CARBON(S);10KOHM,5%,1/2W,AA,TP,2.4X6.4
R228 2001-000117 R-CARBON(S);68OHM,5%,1/2W,AA,TP,2.4X6.4M
R207 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R213 2001-000232 R-CARBON;1.3KOHM,5%,1/8W,AA,TP,1.8X3.2M
R822 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M
R824 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M
J904 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R102 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R103 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R203 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R204 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R231 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R232 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R604 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R605 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R610 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R611 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R612 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R613 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R627 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R628 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R706 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R707 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R708 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R723 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R907 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R909 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R925 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R940 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R941 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R942 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R947 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R948 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R202 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R205 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R206 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R243 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R245 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R246 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R309 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R310 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R606 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R620 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R629 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R715 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R716 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R919 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R935 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R241 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
R208 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM
R242 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM
R214 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R209 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R216 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R234 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R235 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
Electrical Parts List
Samsung Electronics 7-3
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
